4" Easy Chuck™
Easy Chuck Jaws™
The Easy Chuck allow you to change out jaw sets in less than 30 seconds. The pat-
ent pending Snap Lock Technology uses no jaw screws or wrenches to exchange
jaws. You simply use the supplied Jaw Key to depress a keeper latch in the jaw and
slide the jaw right out.You slide in the next jaw type until you hear the unique Snap
sound. This gets you back to turning quickly with the jaws you need to hang onto
you project securely. The Easy Chuck's Zoom Ring gives you the ability to open and
close the chuck very quickly for various gripping diameters with just your finger-
tips. Use the Zoom Ring to bring the jaws into position to lightly grab your project
then use the supplied chuck key for final tightening. The Easy Chuck is available in
three thread sizes: 1" - 8 tpi, 1¼" - 8tpi and M33 x 3.5 (all are 4" in diameter).
10769
1"- 8 tpi Easy Chuck C-1000.....................................................................................
$399.99
10777
1¼" - 8 tpi Easy Chuck C-2000 ................................................................................
$399.99
10778
M33 x3.5 Easy Chuck C-3000...................................................................................
$399.99
10776
1¼" Easy Spindle Adapter
(1-1/4"- 8 tpi female to 1" - 8 tpi male)
.................
$39.99
When you're ready to grip a different part of your turning project, you will need to
change to different size or different shape jaw set in order to work safely and have
the best results. Shown above are six jaw sets. The first jaw set (A) already comes
with the Easy Chuck and may be purchased separately if needed. The Easy Chuck
shown in the images above do NOT come with the jaw chuck sets. The Easy Jaws
are all Smooth Dovetails and they are only compatible with the Easy Chuck.
•
Snap Lock Jaws
•
Zoom Ring Adjust
•
Change jaws quickly
Zoom Ring
Adjustments
Snap Lock
Technology
Jaw Key
& Chuck Key
Changing Chuck
Jaws just got a
whole lot easier!
Chuck jaws for
different size and
shaped projects
Easily work the base of your
turning with the Big Easy Jaw...
Easy Jaws designed for use with the
Easy Chuck only
PLU#
Description
Grips
(tenons)
Expands
(recess)
Jaw
Length
Price
A
10770
1-3/8" Jaws
(comeswithchuck)
1-3/8"
2"
7/16"
$59.99
B
10771
2-3/8" Jaws
2-3/8"
3"
7/16"
$69.99
C
10772
1/2" Reach Jaws
1/2" Str.
1-1/4"
1-1/4"
$69.99
D
10773
1-3/8" Reach Jaws
1-3/8"
2"
1-1/4"
$69.99
E
10774
3-1/2" Reach Jaws
3-1/2"
4-1/4"
1"
$89.99
F
10775
3-1/2" Stepped Jaws
2½", 3, 3½" 4-1/4"
1"
$89.99
A
B
C
D
E
F
Big Easy Jaw™
• Soft Gripping on the rims of bowls, platters and
hollow forms
• Reverse chuck both small and large projects on
lathes up to 20”
• Urethane grippers will not mark your project
• Snap-Lock Technology to Install on your Easy
Chuck in about 30 seconds!
When working with hollow forms, bowls or platters it can be quite cumbersome to
work the base of your project with out damaging or marring the rim. With the Big
Easy Jaw you can easily chuck your project without any fear of marking or marring
your piece since it will rest against the urethane Grippers. The Big Easy Jaw uses
Snap Lock Technology which makes it easy to install on your Easy Chuck in about
30 seconds. The Big Easy Chuck is available in two sizes: 12”and 16”and also 20”Big
Easy Jaw Extensions are available for use with the 16”Big Easy Chuck.
10786
12”Big Easy Jaws CJ512 .............................................................................................
$129.99
10787
16”Big Easy Jaws CJ516 .............................................................................................
$139.99
10788
20”Big Easy Jaw Extensions CJ520.........................................................................
$69.99
10789
2”Easy Reach Urethane Gripper 8 pack................................................................
$29.99
Ron Browns Best™ Longworth Style Chuck
Longworth Style Lathe Chucks are the perfect solution for finishing plates, platters,
bowl bottoms and more. The chuck has a unique self centering mechanism that
automatically adjusts to the size of your project and is easy to secure. A 2-1/4" chuck
adapter is mounted to the back of the Longworth Style Chuck which mounts to a
lathe using a 4 jaw standard chuck (#2 or 50mm). This allows you to mount and
remove the Longworth Style Chuck quickly and easily. Your project is secured by
rubber gripping buttons that provide pliable firm gripping power when tightened.
The chuck is made from 1/4" phenolic plates for years of service and performance.
Please note that the 4 jaw chuck is NOT included.The Longworth style chuck comes
with all the necessary hardware including the gripper buttons for holding the
workpiece. 20”, 24" Longworth Style Chucks andmore information available online.
7365
10" longworth style chuck .......................................................................................
$139.99
7366
12 longworth style chuck ........................................................................................
$149.99
7367
14" longworth style chuck ......................................................................................
$179.99
7368
16" longworth style chuck ......................................................................................
$199.99
7369
8 each replacement Gripper Buttons with hardware ....................................
$24.99
7370
8 each replacement Gripper Buttons only .........................................................
$19.99
Backside
Mounting Plate
R
o
t
a
t
e
t
h
e
c
h
u
c
k
t
o
m
o
v
e
t
h
e
g
r
i
p
p
e
r
b
u
t
t
o
n
s
i
n
a
n
d
o
u
t
The morse taper drill chuck works directly on your lathe. Once inserted into your
lathe tailstock, it will allow you to use your lathe like a horizontal drill press. The
chuck will hold forstner bits, twist bits and more with shanks up to 1/2”. This gives
you the ability to bore out many different types of turning projects like vases, pep-
permills, boxes and more! The Tapered lathe drill chucks are available in Morse Ta-
per 1 and Morse Taper 2 sizes.
7373
MT-1 Tapered Drill Chuck....................................................................................
$34.99
7374
MT-2 Tapered Drill Chuck....................................................................................
$34.99
Tapered Lathe Drill Chuck
Turn your
lathe into a
horizontal
drill press
Woodturning Chucks
