167 / 208
Your One Stop Supply Shop”
167
TheMultiRest is compatible with lathe swing sizes frommini
up to 20”. The base of the MultiRest has independently ad-
justable spacer blocks that provide a secure fit on lathe beds
with way sizes from 1”to 4.5”in width. Each wheel assembly
can be positioned anywhere around the ring to adjust the
center position for a wide range of lathe sizes and project
diameters. The 2-piece design allows the MultiRest to be
opened - leaving the mounting base firmly attached to the
lathe. This provides access when mounting or demounting
parts for secondary operations. When separating the larger
ring section, the remaining section becomes a bowl rest,
providing support behind the work piece while exposing
the opposite side for cutting operations. The device’s multi-ring aircraft grade aluminum structure creates great
rigidity while keeping the weight to half that of a full steel rest. The MultiRest’s bearing mounted, non-marring
urethane wheels have rigid internal rings to prevent sidewall flex, thus giving exceptional support while still be-
ing gentle on the workpiece.
Shown with Carter Hollow Roller Assembly (NOT included)
4210
Carter Multi-Rest
.............................................................................................................................................................................................
$359.00
4211
Carter Multi-Test Replacement Wheel
.................................................................................................................................................
$14.95
4212
Carter Multi-Rest Add-onWheel Assembly
.....................................................................................................................................
$49.95
Carter™ Perfect Sphere Tool
Have you ever wanted to turn a sphere, but just
couldn’t get it perfect? Now you can turn that round
vase, baseball, basketball or any other sphere shape
you candreamup.The Perfect Sphere™Tool is a sphere
and concave turning system adaptable to most lathes
on the market. The heavy duty construction and flex-
ible configuration allow you to turn spheres from 1”
to 14” in diameter on most lathes from 10” to 25”. A
Hunter Tool #4 carbide cutter provided with each
system enables the tool to cut the material versus a
standard scraper which provides for a smooth cut and
long lasting cutter head. The system comes with an
adjustable mounting base. The only part that is lathe
specific is the riser post which is available to fit lathes
from 10”to 24/25”
4415
Perfect Sphere with 10”Riser Stud ..............
$349.95
4416
Perfect Sphere with 12”Riser Stud ..............
$349.95
4417
Perfect Sphere with 14”Riser Stud ..............
$349.95
4418
Perfect Sphere with 16”Riser Stud ..............
$349.95
4419
Perfect Sphere with 20”Riser Stud ..............
$349.95
4420
Perfect Sphere with 24/25 Riser Stud.........
$349.95
Add on the
Carter Laser
Attachment for
even greater
accuracy
Carter® MultiRest™
Turners Laser Guide
Carter® Hollow Roller
The made in the USA Hollow Roller™ system is a cap-
tive bar tool for safely turning hollow forms and bowls.
The bar is completely captive, which allows the opera-
tor to focus on the work of the vessel being turned
instead of on the complexity of the hollowing system.
It incorporates a fully sealed bearing lubrication free
roller system that eliminates drag on the bar, thus
enabling a smoother flowing motion. It gives the op-
erator more control and feel while turning the work
piece. The Hollow Roller attaches to most lathes, but
must be purchased with the correct size adapter stud
(shown below and sold separately)
.
4227
Carter Hollow Roller
...............................................
$359.99
4228
5/8" Adapter Stud
.......................................................
$19.95
4229
3/4" Adapter Stud
.......................................................
$19.95
4230
1" Adapter Stud
...........................................................
$24.95
4231
1-1/8" Adapter Stud
..................................................
$24.95
4235
Hollow Roller Laser Attachment
...................
$149.00
LaserAttachment
SoldSeparately
The Turners Laser Guide enables you to know the location of a point on the cutting edge in real time even while
the vessel is spinning and material is being removed. It utilizes a laser pointer to indicate the cutter position on
the outside of the vessel while the cutter is actually inside the vessel and is otherwise impossible to accurately lo-
cate.The Universal Mounting Base allows theTurners Laser Guide to be attached tomost any style, type or brand
of hollowing tool.TheTurners Laser Guide can be attached to either the turning tool ferrule or shaft ranging from
3/4”to 1-1/4“ in diameter. With the stainless steel supports you can turn vessels 10”deep by 20“ in diameter. The
Turners Laser Guide can be set to show the position of the cutter or to show the offset to give you the ability to
see the wall thickness of your vessel while it is spinning. The Support Arm Accessory Kit (sold separately) gives
you the ability to use theTurners Laser Guide on vessels that are 20" deep by 38" in diameter.The 10”x 20”Turners
Laser Guide includes 1 each of the following: Laser Pointer, Thickness Gauge, Universal Mounting Base, Upright
Support Arm, 90° Bidirectional Bracket, Laser Support Arm, Height Stop Ring and a AAA Battery
7386
10" x 20" Turners Laser Guide...............................................................................................................................................
$79.99
7394
20" x 38" Support Arm Accessory Kit................................................................................................................................
$29.99
Accurately see your cutter location
on the outside of your vessel while
it is spinning and material is being
removed
Easily set the Turners Laser Guide
for the wall thickness of your ves-
sel using the included thickness
gauge
The laser pinpoints the exact
location of your cutter so you don’t
have to worry about cutting too
much or too little.
LaserBeamisnotvisiblewhileinuse.Shownforillus-
trationpurposesonly.TurningToolNOTincluded.
Ron Browns Best™ Steady Rest
Keep your turning projects from wobbling or potentially
breaking off while turning with Ron Brown’s Steady Rest.
Attach the Steady Rest to any lathe with a split bed or
double rail setup. With the unique swing arms, the Steady
Rest gives you total control of the placement of the ball
bearing wheels. This allows you to keep your project rotat-
ing smoothly while hollowing out vessels or turning longer
spindle projects. The unique design of the Steady Rest al-
lows you to easily install and adjust for any type of turning
project. When the top is opened, you can easily remove
your project without having to remove the Steady Rest
from the lathe. Configure the Steady Rest using all three
wheels to keep your workpiece in place with no wobble.
Remove the top from the Steady Rest for working on plates,
dishes and more.
7387
10”- 12“ Ron Brown’s Steady Rest (works with 10 and 12”Lathes)....................................................................
$159.00
7388
16“ Ron Brown’s Steady Rest (works with 16”Lathes).............................................................................................
$189.00
Woodturning Accessories
