Peachtree Woodworking Supply

166 / 208

ptreeusa.comfind even more at order by phone (toll free) at
1-888-512-9069 166
PLU#
Manufacturer
Part #
Post
Dia.
Post
Length
(Assembled)
Fits
Lathe Type Price
6400 5-8TP 5/8” 313⁄16" Jet Mini & Delta Midi Lathes $15.95
6401 5-8TPD 5/8” 43⁄16" 12½”Swing Delta Midi Lathe $16.95
6402 5-8TPR 5/8” 49⁄16" Rikon Lathes $16.95
6403 5-8TPJ1220 5/8” 5¼" Jet 1220 & 1221 Lathes $17.95
6404 25MMG076 25mm 8" Grizzly Model G0766 Lathe $36.95
6405 1TPD/S/01224 1” 43⁄16" Delta HD, 12”(Post 12/2000), 14” & Oneway 1224 $21.95
6406 1TP 1" 411⁄16" Jet/Delta/General 260 $21.95
6407 TPJ1442 1" 47⁄8" Jet 1442 Lathes $24.95
6408 NOVATP/1TPJ1642 1" 57⁄8" Nova 1500/3000, DVR, DVR XP & Jet 1642 $25.95
6409 1TPL 1" 7" Oneway 2436 Lathe $26.95
6410 1TPRO 1" 73⁄8" Robust Lathes $32.95
6411 PM3520A/4224 1 8" Powermatic 3520A, 3520B, & 4224 $31.95
6412 PM3520 11⁄8" 8" Powermatic 3520 $39.95
Lathe Tool Rests
Best Wood Tools - Modular Tool Rests
BestWoodTools - Bars
BestWoodTools - Posts
A
D
E F
B
C
6413 2" long x 3/4" dia. Standard Bar (A)................ $19.95
6414 3" long x 3/4" dia. Standard Bar (A)................ $20.95
6415 4" long x 3/4" dia. Standard Bar (A)................ $21.95
6416 5" long x 3/4" dia. Standard Bar (A)................ $22.95
6417 6" long x 3/4" dia. 2" & 4" Offset Bar (B)........$23.95
6418 6" long x 3/4" dia. Standard Bar (A)................ $23.95
6419 9" long x 3/4" dia. 3" & 6" Offset Bar (B)........$29.95
6420 9" long x 3/4" dia. Standard Bar (A)................ $29.95
6421 12" long x 3/4" dia. Standard Bar (A).............. $35.95
6422 12" long x 1" dia. Super Long Bar (C) .............$41.95
6423 15" x 1" dia. Super Long Bar (C) .......................$48.95
6424 18" x 1" dia. Super Long Bar (C) .......................$57.95
6425 1" wide x 3½" Long Box Flat Bar (D)............... $49.95
6426 1" wide x 4" Long Box Flat Bar (D)................... $59.95
6427 3" Radius x 3/4" dia. Bowl Bar (E)..................... $39.95
6428 4½" Radius x 3/4" dia. Bowl Bar (E).................$39.95
6429 6" Radius x 3/4" dia. Bowl Bar Bar (E).............$39.95
6430 3" Radius x 3/4" dia. Bowl & Ball Bar (F) ........ $39.95
6431 4½" Radius x 3/4" dia. Bowl & Ball Bar (F).....$44.95
6432 6" Radius x 3/4" dia. Bowl & Ball Bar (F) ........ $49.95
EZ Glide Lathe
Toolrest Sets
Pen Turners EZ Glide Toolrest
Spindle Turners EZ Glide Toolrest
Bowl Turners EZ Glide Toolrest
With the unique
design, this toolrest
is the perfect size and
fit for turning pens
and small projects
Your fingers
will fit snuggly
on the rest to
get you closer
to you work
Top
View
With the unique concave design, your fingers will fit
snuggly on the rest and let you get closer to your
work. Includes EZ-Glide Toolrests with 3½”& 6”sup-
ports for single or multi tube pens 5⁄8” dia shaft, 4”
and 4½”high overall.
7502 2 pc Pen Turners EZ Glide Toolrest Set .. $39.95
Comfortably designed tool rests
that will provide you all-day
turning support. The ultra smooth,
round hardened steel top will let
you effortlessly glide your lathe
tool. All rests have a hardened steel
5/16” rod welded over a 5/8 ” bar-
stock. Rod will not nick or scratch
giving it a long life.
Excellent support for spindles short or long. With
the unique concave design, your fingers will fit
snuggly on the rest and let you get closer to your
work. Includes EZ- Glide Toolrests with 9 in. and 12
in. long supports - shaft 5/8 in.x 4-1/2 in. long.
7503 2 pc Spindle EZ Glide Toolrest Set.............. $59.95
With the unique concave design, your fingers will
fit snuggly on the rest and get you closer to your
work. Rests have hardened 5/16” rods welded over
5⁄8”. curved barstock 4”long top to bottom. S Curved
toolrest, 9” span. The S curved toolrest for exterior
and interior hollowing. 3¾”long top to bottom. 2½”
Radius curved toolrest, 6¾”span. Use the 2½”radius
curved toolrest for exterior and interior hollowing.
3 ¾” long top to bottom. 2” radius curved toolrest,
6½” span. Use the 2” radius curved toolrest for ex-
terior and interior hollowing. 4 in. long top to bot-
tom. 1½” radius curved toolrest, 8 in. span. Use the
1½” radius curved toolrest for interior work, deeper
penetration and sharper corners inside the bowl. 4”
long top to bottom.
7504 4 pc Bowl Turners EZ Glide Toolrest Set... $69.95
The T-Bar Modular Tool Rest System gives you the ability to interchange tool bars (tool bars and posts sold sepa-
rately) on to any of the tool posts in the Modular Tool Rest System. This means that you can have multiple posts
for different lathes in your shop and simply change the bar (tool bars sold separately) to the one that you need
for any application. These high quality tool bars feature a 3/4" round guide bar made from super strong, preci-
sion ground polished alloy steel for vibration free turning. The round design offers the smoothest surface pos-
sible for gliding your tools over your project. Wood turners who have used this system say its absolutely the best
they have ever used.
Choose your post size based on your needs for your lathe. Each
Post comes with a brass fitting to accept the
Best Wood Tool - Tool Bars
Choose your bar based on your turning needs. Each tool bar will
fit any of the posts above. The 1" diameter Super Long Bars come
with a larger brass adapter to properly distribute the weight.
Red dotted line denotes approximate mounting hole location.
1.
Choose Your
Post
Choose the correct
size post to
fit your lathe
2.
Choose Your
Bar
Choose your bar
based on your
turning needs
1.
Choose Your Post
Choose the correct size post
to fit your lathe
2.
Choose Your Bar
Choose your bar based on your
turning needs
NEW
