Peachtree Woodworking Supply

169 / 208

Your One Stop Supply Shop” 169
A
B
C
Robert Sorby Patriot Face Plate Rings
Robert Sorby Patriot Wobble Chuck
4Way Chuck & Jaws
Ron Browns Best™ Deluxe Chuck System
The design of these rings incorporates
a milled 2” dovetail on the back of the
plates to fit standard 2” Patriot jaws.
The face plates work like ordinary face
plates do but are much more straight-
forward and convenient to fit and
handle than most other face plates.
The face plates are available in two dif-
ferent sizes: 3-1/8” outer diameter for
smaller projects and 4-3/4” for larger
projects.
The Wobble Chuck is an inexpensive introduction to off-center or eccentric
turning, the Wobble Chuck fits in the standard 2” jaws of the Patriot chuck. The
workpiece can be held by three screws - like a faceplate - or by a single wood screw
- like a screw chuck - or by both means. It is then off-set by rotating the upper sec-
tion of theWobble Chuck. Ideal for goblets with off-set stems. A great opportunity
to experiment with novel projects.
4 Way Chuck
The 4 Jaw Chuck (A) has a wide range
of jaw movement and a powerful grip.
Jaws expand and grip in a 2”to 3”dove-
tail recess. Chuck is chrome plated to
protect against corrosion while jaws
are anodized black. Supplied standard
Jaws hold round stock between 15⁄8 ” to
2¾” or square billets 11⁄8” to 21⁄8” in size.
Includes: 4 jaw chuck, standard jaws, t-
handle wrench, screw center, threaded
adapter, 2 each locking levers and 8
each jawmounting screws.
Jaws for 4 Way Chuck
Pin Chuck Jaws
Pin Chuck Jaws (B) are perfect for
smaller turning projects like pen mak-
ing. These chuck jaws hold stock from
3⁄8” to 13⁄8” on the inside of your stock
and 11⁄16” to 21⁄16” on the outside of your
stock.
#3 Chuck Jaws
#3 Jaws (C) are ideal for larger bowls
and turnings. These jaws will hold
workpieces from 3¼” to 4¼” on the in-
side of your stock and 3 13⁄16”to 413⁄16” on
the outside of your stock.
The 3-3/4” Ron Brown 4 Jaw Woodturning Chuck Deluxe Set is an easy to use,
fully accessorized, key operated self centering lathe chuck system. To operate this
chuck, all you need is one hand, as the “T” handle key enables you to tighten the
jaws with one hand while your other hand is free to support your work. 11106 3-1/8”Patriot Face Plate Ring FPR80 ........................................................$25.99
11107 4-3/4”Patriot Face Plate Ring FPR120 ......................................................$29.99
11112 Patriot Wobble Chuck RSWC.....................................................................$99.99
7342 Ron Browns Best Deluxe Chuck System...........................................................$189.99
7526 4 Jaw Chuck with ¾”x 16 TPI threads (A) ................................................................$99.99
7527 4 Jaw Chuck with 1”x 8 TPI threads (A)....................................................................$99.99
7528 4 Jaw Chuck with 1¼”x 8 TPI threads (A) ................................................................$99.99
7578 4 Jaw Chuck with ¾”x 16 TPI threads with both sets of Jaws (A,B & C)......$149.99
7579 4 Jaw Chuck with 1”x 8 TPI threads with both sets of Jaws (A,B & C)..........$149.99
7580 4 Jaw Chuck with 1¼”x 8 TPI threads with both sets of Jaws (A,B & C)......$149.99
7547 Chuck Pin Jaws (B) ............................................................................................................$21.99
7548 #3 Chuck Jaws (C)..............................................................................................................$34.99
Includes 4
sets of chuck
jaws!
Works with the Patriot Chuck
Not included
•1 ea. 3-3/4”4 jaw chuck
•1 ea. T-handle wrench
•1 ea. screw center
•1 ea. #1 step jaws
•1 ea. #2 round jaws
•1 ea. #3 round jaws
•1 ea Head stock adapter
•1 ea T-Handle HexWrench
This set includes:
Barracuda™ Lathe Chuck System
Barracuda™ 2 Lathe Key Chuck System
Keyed operation allows you to use one hand to tighten the jaws while your other
hand can support your work. Self centering and ideal for small cup projects, minia-
tures and small spindle work. This premium 4-jaw self-centering chuck system fits
mini, midi and micro lathes. Adapts to lathes with either 3/4" x 16tpi or 1" x 8tpi.
Self-centering heavy duty chuck for full-size lathes makes easy work of your heavi-
est and largest turnings. The geared key mechanism provides a powerful grip ca-
pable of holding large work. Designed for lathes with 10" swings or larger. Includes
Pin,#1,#2,#3,Screw Chuck. Weighs 8 lbs with a 4.5" diameter. Body thread 1" x 8 tpi.
7047 CSC2000C Barracuda 3 Micro Lathe Key Chuck System...................................$139.99
The Barracuda2 is an easy to use, high-performance, full accessorized key operated
self centering four-jaw lathe chuck system.You only need one hand to use this lathe
chuck as the "T" handle jaw tightening key enables you to to tighten the jaws with
only one hand while your other hand is free for support.
7048 CSC3000C Barracuda 3 Micro Lathe Key Chuck System...................................$189.99
7046 CSC500K Barracuda 3 Micro Lathe Key Chuck System ......................................$134.99
Barracuda™ 3 Micro Lathe Key Chuck System
Woodturning Chucks
Ideal for larger
stock
Perfect for
smaller turning
projects
