Dust Collection
4”Router Dustport
is a combination of the 4”to 2-1/2”
reducer and the right angle router dustport. The small
end on the 4”to 2-1/2”reducer fits perfectly inside the
right angle port so you can then attach a 4” hose to
the larger end of the reducer with a hose clamp
(see
page 44)
. This unit will fit on just about any router
table fence system.
0469
(A and B) 4”router dustport ..................................................................................
$7.99
0441
(A) 4” to 2-1/2”reducer ...........................................................................................
$3.99
0386
(B) right angle dustport ..........................................................................................
$4.99
2
½
” Low Profile Dustport
directly accepts a standard
2
¼
” Shop-Vac® hose end in the dustport opening.
You can also attach a standard 2-1/2” dust collection
hose around the outside of the dustport opening
with a single hose clamp
(see page 44)
. The fitting itself
attaches to the back of most router fences with two
standard wood screws. Low profile makes this fitting
an excellent add-on to any drill press fence system.
0453
2-1/2”Low Profile Dustport ...................................................................................
$3.99
2
½
” Extended Dustport
directly accepts a standard
2
¼
” Shop-Vac® hose end in the dustport opening. No
hose clamp is required for this type of connection. You
can easily attach a standard 2-1/2”dust collection hose
around the outside of the extended dustport opening
with a single hose clamp
(see page 44)
. The fitting itself
attaches to the back of most router fences.
0452
2-1/2”Extended Dustport.......................................................................................
$4.99
Router Table Dust Ports
PLU Size
Outer
Diameters
Price
0468
4”
2
¼
”x 4”
$5.99
2¼” to 4” Enlarger
is a fitting made of flexible plastic. This is one of those fittings
that woodworkers have wondered, why don’t they make a fitting that goes directly
from my 4” hose into my Shop-Vac®? Well, here it is, an enlarger that accepts a
4” hose on one end and the other plugs directly into a standard 2¼” Shop-Vac®
opening. A hose clamp is required on the 4”end for proper connection
(see page 44).
2½” to ¾” Rubber
Adapter
PLU Size
Outer
Diameters
Price
0434
2½”
2
½
”x ¾”
$6.99
The 2½” to ¾” Rubber Adapter
large end will fit in a 2-1/2” shop vacuum hose. A
flexible construction allows easy connection to any of your power tools. O.D. sizes:
2-1/2”, 2”, 1-1/2”, 1-1/4” and 1”. I.D. sizes are 1/4” less than the O.D. sizes. Simply cut
it to the size needed for the proper I.D. and O.D. fitting. Hose clamps are required.
4”to 1”Adapter (A)
is tapered from the 4”O.D. to the 1”O.D. Cut the adapter at the
desired diameter to fit to your machine port or smaller I.D. hose. Flat portions are
at sizes of: 4”, 3”, 2-1/2”and 1”for hose to hose splices. Hose clamps are required.
4”to 1”Rubber Adapter (B)
has the exact same dimensions as the standard plastic
adapter.The difference is that this adapter is rubber which gives you the ”flexibility”
to adapt it much easier than plastic. You can use the adapter in its full size or you
may cut it at the needed spot for just the right fit. Hose clamps are required.
6” to 1” Adapter
PLU Size
Outer
Diameters
Price
0435
6”
6”x 1”
$7.99
6” to 1” Adapter
is a six step down adapter for a variety of different types of
hookups.. The step down sizes are 5”, 4”, 3”, 2½”, 2”, ” and 1”. May be cut to fit your
particular needs. Hose clamps are required for proper connection
(see page 44)
4” Router Dustport
2½ Low Profile Dustport
2½ Extended Dustport
A
B
2¼” to 4” Enlarger
Router/Bandsaw
Dustport
PLU Size
Outer
Diameters Price
0387
2
½
”
2
½
”
$3.99
0389
4”
4”
$4.99
Circular Mount
Dustport
PLU Size
Outer
Diameters Price
0503
2½”
2
15⁄32
”x 3
½
”
$3.99
0504
4”
3
7⁄8
”x 5
9⁄16
”
$4.99
2
½
”& 4”Router / Dustport
are two of the most popular fittings used in creating an
airway on you router table, bandsaw or any other machine that does not come with
a dustport. The 2-1/2” fitting attaches with 4 screws (not included) on each corner,
while the 4”requires two. The dustports will accept a 2-1/2”& 4”hose respectively.
A hose clamp is required for this type of connection. This 2-1/2” (A) fitting will also
accept a standard 2
¼
” Shop-Vac® hose end. Hose clamp is required for this type of
connection
(see page 44).
The 2½”dustport can be attached to bandsaws with a smaller dust collection open-
ing. This dustport must be drilled for mounting to your machinery. The 4”dustport
can be attached to bandsaws with a larger dust collection opening. This dustport
has four pre-drilled holes for easy mounting to a bandsaw or other machinery.
Hose clamps are required for proper connection (see page 44).
Easily attach dust
collection hose
to machinery
An easy way to hook
up dust collection to
bandsaws and router
tables
PLU Fig.
Outer Diameters
Inner Diameters
Price
0521
A
1
3⁄8
”x 1
½
”
1
1⁄8
”x 1
¼
”
$3.99
0522
B
1
½
”x 1
15⁄16
”
1
¼
”x 1
11⁄16
”
$3.99
Having difficulty connecting odd sized tool openings or European size fittings? The
Flexible Rubber Fittings are a perfect solution. The soft rubber fitting will stretch,
flex and give allowing for a tight connection on a number of small power tools.
Flexible Rubber Fittings
A
B
Great for attaching odd
sized tool openings
A
B
4” to 1” Adapters
PLU Size
Outer
Diameters
Price
0433
4”
4”x 1”
$5.99
0542
4”
4”x 1”
$7.99
(A)
(B)
