Peachtree Woodworking Supply

38 / 208

ptreeusa.comfind even more at order by phone (toll free) at
1-888-512-9069 38
PLU Fig.
Outer Diameters Inner Diameters Price
0529 A 331⁄32” x 4”threaded 325⁄32” x 3¾” $6.99
0528 B 3 31⁄32”x 43⁄16” 325⁄32”x 315⁄16” $6.99
A
B
The PVC Threaded Screw adapter ( A) allows you to go from 4" DWV PVC pipe com-
monly available at home-centers to 4" dust collection hose (Works with all our 4" dust
collectionhose ).The Standard PVC adapter (B) allows you to go from4" DWV PVC pipe
to 4" dust fittings like Y's, T's and elbows. You can go from 4" DWV PVC pipe directly
to 4" fittings with this one adapter. Warning: PVCpipemustbegroundedforstaticelectricity.
DWV - PVC Fittings
Quick Connect
Swivel Ball Joint
PLU Size Outer Diameters Price
0477 2½” 4¼”x 2½” $8.99
0478 4” 4¼”x 4” $8.99
The ball joint fitting is designed to be pressed on to any 4”tapered diameter open-
ing for a quick and easy fit. Ball joint prevents twisting of hose at the connection
point which allows for great mobility. The opposite end accepts a 4” hose. A hose
clamp is required on one end for proper connection (see page 44).
Dust Collection
4”Threaded Quick
Disconnect Blast Gate
Blast gates maximize system ef-
ficiency. With gates that open and
close the blast gates allow you to
shut off specific lines, giving more
air flow to the machine your work-
ing with. The blast gates are eco-
nomically priced, and have a smooth
surface and an easy slide in and out
action. Note: Hose clamps are required for
proper connection of hose to blastgates (see
page 44). The quick disconnect blast gate makes it easy to con-
nect and disconnect from your machinery. It works
just like a standard blast gate, only this blast gate has
a tapered end to make fitting it onto a machine easy.
Attaches to most machines with a 4”opening.
Note: Hose clamps are required for proper connection (see page 44).
Made from aluminum,
theseblastgateswillstand
the test of time. Each blast
gate hase a threaded lock
knob to keep the gate
open or closed as needed.
Aluminum blast gates are
also great for grounded
dust collections systems.
Note: Hose clamps are required
for proper connection of hose to
blastgates (see page page 44).
Tired of constantly having
to clean the build up of
dust & debris out of your
blast gates? With the new
through blast gates, the
gate slides all the way
through the casing which
in turn cleans out the
blast gate every time you
open it.
0475 2½”Aluminum Blast gate ......2½”x 2½”...........$9.99
0396 3”Aluminum Blast gate ..........3”x 3”................. $9.99
0397 4”Aluminum Blast gate ..........4”x 4”...............$10.99
0476 4”Alum. Through Blast gate...... 4”x 4”...........$12.99
0398 4”Quick Connect Blast gate...... 4¼”x 4”..........$4.99
0473 4”Double thread blast gate...... 4”x 4”.............$6.99 0483 4”threaded blast gate................. 4¼”x 4”.........$6.99
Blast Gates Quick Connect Blast Gate Aluminum
Blast Gate
The threaded blast gate
allows you to connect
your 4" hose directly to
the opening of the blast
gate without the use of a
clamp. The gate is thread-
ed on both ends. You sim-
ply attach your 4" hose by
screwing the hose on the
threads of the blast gate.
The threaded quick dis-
connect blast gate allows
you to connect your 4"
hose directly to the open-
ing of one end of the blast
gate without the use of
a hose clamp. The blast
gate has tapered quick
connect opening on the
opposite side for easy
connection.
Closed
Gate
Open
Gate
AluminumThrough
Blast Gate
4”Threaded
Blast Gate
0391 2½”ABS Plastic Blast gate...2½”x 2½”.............$3.99
0392 3”ABS Plastic Blast gate.......3”x 3”....................$3.99
0393 4”ABS Plastic Blast gate.......4”x 4”....................$3.99
0394 5” ABS Plastic Blast gate......5”x 5”....................$5.99
0395 6”ABS Plastic Blast gate.......6”x 6”....................$6.99
Insert into DWV-PVC pipe
and thread on your hose
Attach a standard dust
collection fitting to
DWV-PVC pipe
4½" to 4" Adapter
PLU Size Outer
Diameters Price
0425 4½” 4 ½”x 4” $5.99
4”Quick Connect
PLU Size Outer Diameters
Price
0420 4” 4”x 4¼” taperedend $6.99
4”Quick Connectis designed to be pressed on to any 4”tapered diameter opening
for a quick and easy fit.The opposite end accepts a 4”hose. A hose clamp is required
on one end for proper connection(see page 44 ).
4”Threaded Quick Connect
PLU Size Outer Diameters Price
0421 4” 4”threadedend x 4¼” taperedend $6.99
4”Threaded Quick Connect is designed to be pressed on to any 4” taper diameter
opening for a quick and easy fit. The opposite end will accept a 4” hose by simply
threading it on . No hose clamp required.
4-1/2”to 4”Adapter is used to connect your dust collection line to your standard 4”
dust collection hose. Hose clamps required for this connection. (see page 44)
