Dust Collection
A
D
F
No more scraping or busting knuckles to attach your hose to your dust collection
fittings. The EZ Release Hose Clamps are designed to create strong spring like pres-
sure on the hose when released. Simply squeeze the EZ Release Hose Clamp, place
around your hose, and then attach to your dust collection port or fitting. These
clamps are available in two convenient sizes and are sold individually.
0493
1ea. 2½" EZ Release Hose Clamp...............................................................................
$1.79
0494
1ea. 4" EZ Release Hose Clamp ..................................................................................
$2.49
Fifty foot grounding kit makes your dust collection system safer by grounding your
dust collection hose or pipes to prevent static. The kit includes 50 feet of braided 14
gauge copper wire, grounding screws, wire nuts and terminal ends for a complete
and easy installation process.
0457
................................................................................................................................................
$14.99
Hose Clamps
Hose Hangers
50’ Hose Grounding Kit
Shopfox Wall Mount Dust Collector
Wire hose clamps
(A)
grab around grooves of the hose to form a secure grip around
the fitting or port hole.They secure down with a screw driver or a socket. Steel Hose
clamps
(B)
expand to a large enough size to fit around the hose, then place hose
onto the particular fitting then secure with a screw driver or socket. The thumb-
screw feature on the steel hose clampwith thumbscrew key
(C)
makes it easy to se-
cure these clamps to your hose and fittings. Simply loosen clamp by turning coun-
ter clockwise, place around your hose, and then, place hose on fitting and secure.
Use a hose hanger to run your dust collection hose line throughout your shop.
They fasten to just about any spot on your wall or ceiling simply by driving screws
through the flaps on the ends of the hangers. (screws not included).
No more digging or cutting into your dust collection hose with the NEW Step Over
hose clamps. Unlike standard steel hose clamps, the unique design of these hose
clamps allows the steel bands to "step" over the top of the hose wire (in clear PVC
type hose) and applies pressure where needed. This will keep your fittings more
secure and won't damage your hose. The clamp is equipped with a plastic turn-
key for easy tightening and loosening. The Step Over hose clamp works great with
Peachtree's PVC clear hose (sold separately and available on page 43). Works with
most standard dust collection hoses. These clamps are thread direction specific. As
shown above the blue keyed clamp is for left threaded hose and the yellow keyed
clamp is for right threaded hose. We recommend that you check the thread direc-
tion of your hose before placing an order to make sure that you receive the proper
fit of step over hose clamp.
Step Over Hose Clamps
A simple way
to ground your
dust collection
system
0498
2½”left thread hose clamp....
$1.79
0495
4”left thread hose clamp .......
$1.99
0543
2½”right thread hose clamp
$1.79
0544
4”right thread hose clamp....
$1.99
Right Thread Hose
Right Thread
Clamp
Left Thread
Clamp
Left Thread Hose
B
C
A
Secure your
fittings to your
dust collection
hose
0354
(A)
2½” wire hose clamp............
$1.25
0358
(A)
3”wire hose clamp.................
$1.25
0361
(A)
4”wire hose clamp.................
$1.25
0355
(B)
2½”steel hose clamp..............
$.80
0359
(B)
3”steel hose clamp..................
$.80
0362
(B)
4”steel hose clamp..................
$.80
0356
(C)
2½” clamp w/thumbscrew
$1.25
0363
(C)
4”clamp w/thumbscrew.....
$1.50
0353
2½” plastic hose hanger.........
$.69
0352
2¾”steel hose hanger..............
$.79
0479
4”plastic hose hanger..............
$.89
0360
4”steel hose hanger..................
$.99
EZ Release Hose Clamps
This wall-mounted Dust Collector is designed to capture dust right at the source,
eliminating the reduced efficiency of a duct system. With 537 CFM capacity, it will
handle just about any woodworkingmachine, and without a complicated duct sys-
tem, static pressure loss is minimal. A simple wall-mount bracket and locking screw
system ensures you'll be safely up and running in no time! The bag filter features
a window to gauge dust levels in the bag and a bottom zipper for easy cleaning.
0716
ShopfoxWall Mount Dust Collector........................................................................
$209.99
Specifications
Motor: 1 HP, 120V/240V, single-phase, 110V
Motor amp draw: 7A/3.5A
Air suction capacity: 537 CFM
Static pressure: 7.2"
Intake Hole Size: 4"
Impeller: 10" balanced cast-aluminum
Bag capacity: 2 cubic feet
Bag size (diameter x depth): 13-1/2" x 24"
Standard bag filtration: 2.5 micron
Powder-coated finish
Height with bag inflated: 44"
NEW
