Peachtree Woodworking Supply

39 / 208

Your One Stop Supply Shop” 39
Dust Collection
“Y” Fittings
PLU Size
Outer
Diameters Price
0406 2½” 2½”x 2½” $3.99
0411 3” 3”x 3” $4.50
0415 4” 4”x 4” $5.99
Y - fittings are used to attach branch lines to service more than one machine at a
time. This design provides increased lateral air flow and efficiency over other types
of fittings. Hose clamps are required for proper connection (see page 44).
“T” Fittings
PLU Size Outer
Diameters Price
0407 2½” 2½”x 2½” $3.99
0412 3” 3”x 3” $4.50
0417 4” 4”x 4” $5.99
T- fittings provide the option of adding branches to service eachmachine in a shop.
T’s are very helpful when space or design constraints prohibit the use of Y’s and
other fitting types. Hose clamps are required for proper connection (see page 44).
Elbow Fittings
PLU Size Outer
Diameters Price
0408 2½”/ 90˚ 2½”x 2 ½” $3.99
0538 2½" / 45˚ 2½”x 2 ½” $3.99
0413 3”/ 90˚ 3”x 3” $4.50
0418 4”/ 90˚ 4”x 4” $5.99
0487 4" / 45˚ 4" x 4" $5.99
Elbow fittings eliminate binding or kinking in the hose when you bend the hose
at a 900 angle. Place the Elbow fitting in the corners of your dust collection line to
prevent kinks. Hose clamps are required for proper connection (see page 44).
Splice Fittings
PLU Size Outer
Diameters Price
0409 2½” 2½”x 2½” $2.99
0414 3” 3”x 3” $4.50
0419 4” 4”x 4” $4.99
Splice fittings are used simply to connect two sections of dust collection hose to-
gether. You can use them on long runs of hose line or short runs of hose line. Hose
clamps are required for proper connection (see page 44). The 2-1/2”fitting will accept
a 2-1/4”Shop-Vac® hose. This will allow you to join two Shop-Vac® hoses end to end
with no hose clamps.
4” to 2½” - Y - Fitting
PLU Size Outer
Diameters Price
0416 4”end
2½”end
4”x 4”
2 ½” $6.99
The 4 to 2½”-Y- fitting is used simply to branch off your dust collection line just like
a standard “Y” fitting, only this fitting reduces your branch off down to 2½” . Hose
clamps are required for proper connection (see page 44).
4”Flat End Elbow
PLU Size Outer
Diameter Price
0423 4” 4”x 4” $6.99
The 4” Flat End Elbow is a great fitting that is fastened directly to your machine
when space is limited. There is no need for all the extra little connector pieces with
this one! Hose clamp is required on one end for proper connection. (see page 44)
Connect two
fittings together,
including PVC to
PVC pipe!
45˚
90˚
The 4" three port junction fitting gives you the ability to attach up to three different
machines or tools to one convenient fitting. Works great with tablesaws, jointers,
planers and more! The fitting is designed to be used with 4" hose and requires the
use of hose clamps (not included see page 44 for hose clamps and accessories).
The three port junction fitting has a 4" O.D. and a 3-7/8" I.D. on all four openings.
0535 ................................................................................................................................................ $14.99
Trying to connect two fittings together can sometimes be frustrating. The Fulton
Coupler rids you of this frustration by allowing you to easily connect two of your fit-
tings with a unique design. For example this will allow you to join a“Y”to an elbow,
or even a“T”. It also allows you to join PVC parts without gluing. The steel construc-
tion makes the joint rigid once the coupler is connected so you don't have to worry
about your joint being loose or flimsy.
0536 2½" Steel Coupler ............................................................................................................$6.99
0537 4" Steel Coupler................................................................................................................$8.99
3-Way Junction Fitting
Steel Coupler
A great fitting for adding
more tools to your dust
collection system
Connect two fittings together without cutting out a hose section to do it. For ex-
ample with the rubber coupler you can join a “Y” to an elbow, or even a “T”. The
rubber fitting is perfect for standard dust collection fittings where hose sections
are typically used.
0540 2½" Rubber Coupler .......................................................................................................$7.99
0541 4" Rubber Coupler...........................................................................................................$9.99
Rubber Dust Collection Fitting Coupler
Connector Coupler
Taper to Taper Coupler
Easily connect two
dust collection
fittings
Connect
two fitting
together with
no tools
Connect a
flange to a
blast gate
The Connector Coupling let’s you connect two flat end fittings together with it’s
two compressed ends. With no hose clamps required, this makes attaching two
fittings quick and easy. Example: Y to T, Elbow to Y.
0422 4¼”connector coupler - 4¼”O.D. x 315⁄16”I.D.........................................................$4.99
0485 2½”connector coupler - 2¾”x2¾”inside diameter............................................$3.99
The 4¼” taper to taper coupler allows you to connect two tapered end 4” fittings
together. The inside diameter tapers down on both ends. Example: flange to blast
gate.
0424 4¼”taper to taper coupler - 315⁄16”I.D. tapers down to 3¾”.............................$4.99
