Note: 30 gal. and 5 gal. cans
are required for use with the
separator lids. Cans are not
included.
PLU #0399 shown in drawing
Sawdust and debris
enter through the hose
connected to your
machine.
1
Large particles are
separated from the
dust and remain on the
bottom of the trash can.
2
The remaining fine
dust filters it’s way
through to your
dust collector.
3
Cyclone Separator Lids
This dust collector separator increases
the efficiency and capacity of standard
dust collection systems. Designed to fit
securely on top of a standard 30-gallon
(20" dia.) metal trash can, this molded
ABS fitting is engineered to use cyclon-
ic action to drop out larger particles
from the dust flow. The fitting features
molded inlets and outlets which can be
easily connected to standard systems
using 4” flexible hose (page 42). You
will be amazed at howwell it works!The
separator comes in two sizes: 30 gallon
can size and 5 gallon size.
0399
30 gallon lid.............................
$32.99
0400
5 gallon lid ...............................
$23.99
The cyclone separator with a handle
works by drawing the air downward
as opposed to horizontally, causing
the large debris to settle at the bottom
of the can. This prevents large chips
from passing though the impellers.
Designed to fit on top of a standard
30-gallon (20" dia.) metal trash can.
The separator also has port holes that
protrude to provide an easy hookup for
your dust collection hose. The handle
on the cyclone lid makes cleaning out
the can a snap. Available in 5 and 30
gallon sizes.
0401
30 gallon lid.............................
$34.99
0402
5 gallon lid ...............................
$24.99
Horizontal CycloneLid
Vertical CycloneLid
Help protect your dust collector from unnecessary wear and tear with our unique
Dust Separator Kit. Two elbows and two couplers combine to give you infeed and
outfeed points when they are installed on a barrel, box, or any container (barrel or
box not included) that you would like to capture large wood chips in. The separator
works by simply allowing the heavy wood chips to fall to the bottom of the con-
tainer, while the lighter dust particles get pulled in the outfeed port and into your
dust collector. This keeps the large debris from slamming into your dust collector’s
impeller, which in turn prevents any unnecessary damage to the unit. Separating
the large wood chips also keeps your dust collector bag or container from filling
up so fast, this means you won’t have to empty it as often! The Dust Separator Kit is
perfect for use with Jointers, Planers, Router Table units and more! The Kit includes:
2 ea. 4" Ports, 1 ea. 4" infeed elbow, 1 ea. outfeed elbow, 1 ea. hardware pack and 2
ea. 4" turn key hose clamps.
0530
................................................................................................................................................
$19.99
4" Cyclone Dust Separator Kit
Make your own cyclonic
action dust separator!
Cleardusthoodthatworks
onmostany lathe
Includes strongmagnetic
bracket foreasymounting
Barrel and hose are NOT included
Dust Collection
0539
.........................................................................................................................................
$44.99
Mini Cyclone Dust Collector
With the clear view bucket, the Mini Cyclone makes
it easy to see when it's time to empty the debris.
Not to mention it's also easy to setup and start us-
ing. Simply connect your hoses to the Mini Cyclone
Dust Collector lid and you're ready to go. Once set
up the Mini Cyclone Dust Collector separates the
large debris from the dust.This allows the large par-
ticles to fall to the bottom of the 6 gallon bucket,
which helps protect your shop vacuum from un-
necessary wear. A clear 90
°
elbow is included for
creating the cyclonic action. Works with 2½" hose
only. Hose and hose clamps are not included.
Features a 6 gallon
clear view bucket
Lathe Dust Hood
A clear protective shield that swings up and out of the way. The hood includes a
strong magnetic mounting bracket and clamp for easy adjustments or removal. In-
stant positioning along the length of any lathe without clamps. Works on most any
lathe. A 6”x 9”opening is ideal for pen crafting. Has a standard 4”flange opening.
0405
...............................................................................................................................................
$27.99
Downdraft Table
Downdraft Panels 2 Pack
This Pre-Made Down Draft Box comes with everything you need to draw harmful
dust particles away from the user without obstructing movement or work produc-
tivity. 7" deep x 17-1/4" wide x 28" long down draft box (some assembly required)
with baffles to direct saw dust towards dust port. A 4" dust collection port / blast
gate connects to your dust collection system for efficient dust/chip disposal (hose
not included). Includes 64 non-slip rubber grommets to stabilize your work piece
while sanding or routing. Orange stops are also included to prevent movement
while sanding and are able to be placed in any of the open holes on the plate(s).
0227
Complete downdraft table box with 4 panels....................................................
$89.99
Build your own custom downdraft ta-
ble using our steel down draft panels.
Each plate measures 6¾" x 16½" and
has soft, non-slip rubber grommets
to prevent marking the stock. Orange
stops are also included to prevent
stock movement while sanding and
are able to be placed in any of the
open holes on the plate(s).
3592
2 pack of downdraft panels........................................................................................
$24.99
