103 / 208
Your One Stop Supply Shop”
103
Router Jigs &Templates
1 Ea. 1/4”spacer fence
1 Ea. 3/8”spacer fence
1 Ea. 1/2”spacer fence
1 Ea. Positive stop set-up block
spacing system
™
Spacing System
Individual Spacer Fence Kits
Freud Router Bit's for use with Multi-Joint
The Multi-joint™ spacing system allows you to make 1/4", 3/8" and 1/2" box joints
as well as rabbet, dado, spline and sliding dovetail joints (for drawer glides) to any
width with no limitation. Brass set-up bars (included) make setting up the Multi-
joint very simple. Made from durable laminated MDF with UHMW guide bars for
smooth operation. Platform measures 24" long which will fit across most router
tables. Use your own bits or purchase one of ours. Please Note: This system is de-
signed to be used on table mounted routers only. Full color step by step instruc-
tions are included with the package.
If you simply need to make specific
size box joints on a consistent basis
then one of these convenient kits is
perfect for you. Each one of these kits
include a Multi-joint spacer fence, 1
up-cut spiral bit, brass bar and a right
angle fence. A full set of color instruc-
tions are also included.
3484
Multi-joint™ Spacing System .....................................................................................
$119.99
3485
1/4" spiral for 1/4" box joints .......................................................................................
$14.99
3486
3/8" spiral for 3/8" box joints .......................................................................................
$29.99
3487
1/2" spiral for 1/2" box joints .......................................................................................
$29.99
3488
14° 1/2" dovetail bit .........................................................................................................
$14.99
3583
1/4" spacer fence kit with 1/4" up-cut spiral bit ..................................................
$54.99
3584
3/8" spacer fence kit with 3/8" up-cut spiral bit ..................................................
$69.99
3585
1/2" spacer fence kit with 1/2" up-cut spiral bit ...................................................
$69.99
Sliding Dovetail
1/4" box joint
3/8" box joint
1/2" box joint
Dovetail Wiz™ Dovetail System
Dovetail Wiz™ Accessories
Dovetail Jig Clamping Kit
3457
Mini Dovetail
Bit Set
3454
Small Dovetail
Bit Set
3456
Box Joint Bit
Dovetail Jig Router Bits
The perfect solution for repetitive size box joints.
The Dovetail Clamping kit pro-
vides solid stock support while
making your dovetail cuts. The
clamps are completely adjustable
side to side to accept any width
stock (depending on size of jig
set-up). The clamps fit directly into
the 1/4" x 20 mini T-track (included
with kit). The mini T-track is em-
bedded into a dovetail jig mount-
ing block (make your own or pur-
chase one separately). The 15" kit
includes: 2 ea. T-track Clamps and
2 each 15" long mini T-tracks. You
may also purchase the 15" Tracks in
sets of two without the clamps to
increase your clamping capacity.
The mini dovetail bit set is de-
signed for use with
1⁄8
" to
3⁄8
" thick
stock and used from the second
scribe line on the DovetailWiz™. The
small router bit set is designed to
be used with
¼
" to
½
" thick stock
and work from the first scribe line
of Dovetail Wiz™. The box joint bit
works great for making box joints
/ hinge joints in stock from
½
" to
¾
" in thickness using the tail side
of the jig.
3463
15" clamping kit..................
$39.99
3432
2 pack of 15" Track.............
$14.99
3457
mini bit set............................
$39.99
3454
small bit set ..........................
$39.99
3456
box joint bit..........................
$29.99
3437
All 3 sets in wood box ..
$105.99
2721
1/4" up-cut bit
¼"
shank
..
$19.99
2723
3/8" up-cut bit
½"
shank
..
$51.99
2724
1/2" up-cut bit
½"
shank
..
$67.99
2487
½
" 14
˚
Dovetail
½"
shank
.
$22.99
2502
¾
" 14
˚
Dovetail
½"
shank
.
$29.99
15" Dovetail System:
1 ea. 15’’template
1 ea. dovetail bit (7°) w/ bearing
1 ea. straight bit w/ bearing
1 ea. instruction manual
15" Jig Add-On Kit:
1 ea. 15’’template
30" Dovetail System:
1 ea. 15’’template & manual
1 ea. 15" Add-on kit
1 ea. dovetail bit (7°) w/ bearing
1 ea. straight bit w/ bearing
Make Box Joints Quickly and Precisely with the Multi-Joint System
1 Ea. Dovetail Liner Offset Fence
3 Ea. Right angle fence
5 PC set of Brass Set-up bars
System incudes:
DoubleFluteUp-cutSpiral Bits
14˚Dovetail Bits
Freud's solid carbide up spiral bit's combine effective chip removal with a cut that
can't be matched by standard straight bits. The dovetail bits produce smooth intri-
cate cuts. Both style bits are perfect for the Multi-Joint System
Cutting dovetails on small or large projects has just got-
ten easier. From traditional dovetails to the antique look
of wide spaced dovetails, The Dovetail Wiz™ makes it sim-
ple. The hardest part about cutting dovetails is marking
and cutting the matching angles to one another. Fortunately, we have done
the math for you and milled the exact cuts that need to be made in this easy
to use dovetail jig.This dovetail systemworks with precision bearing guides on
the shank of the router bit instead of using those hard to center brass bushing
guides. Since the bearing is already centered on the bit, there is no slop, no
wear and no waste, making set up fast and easy. Unlike other templates you
have seen, our jig will work with different thicknesses of stock from 1/2" to
3/4" thick. (Optional router bit sets are available for thinner stock or box joints).
It also does not limit your stock width, it's as simple as making your first cut,
then slide the jig down, realign and make your second cut. Or simply attach
an Add-On Jig (sold separately) to your Dovetail Wiz™ and make the longer
width cuts all at once without moving the jig. We have milled male and female
connector tabs on the ends of our dovetail jig. This will allow you to attach as
many Add-On jigs (sold separately) to your Dovetail Wiz™ to create a longer jig
for any size project. . This means the types of projects you can do with this jig
are virtually endless! The connector tabs also accept the NEWMicro-Adjusters
(sold separately) to super fine tune the fit of your dovetail joint.
3452
15" Dovetail Wiz™ system ..................................................................................
$159.99
3453
30" Dovetail Wiz™ system...................................................................................
$259.99
3577
15" Dovetail Wiz™ Add-On kit
(comes with 1 ea. 15" dovetail jig only)
...............
$119.99
3444
Micro-adjuster for dovetail jig .............................................................................
$39.99
3455
replacement router bit set - includes dovetail and straight bit .............
$39.99
3343
Instructional DVD......................................................................................................
$14.99
Create
uniquedove-
tail joints like
standard,
singleskip,
doubleskip
spacingand
more!
