Peachtree Woodworking Supply

100 / 208

ptreeusa.comfind even more at order by phone (toll free) at
1-888-512-9069 100
1061 .......................................................................................................................................................................$4.99
Replace, your old worn out router base plate with this heavy duty aluminum router
base plate. The Aluminum Router Plate is pre-drilled to fit the most common rout-
ers on the market. Two snap-in insert rings for various size router bits and all the
necessary hardware is included. The plate measures 6½” x ¼” . The Snap-in Rings
are interchangeable for easy transitions between multiple router applications.
Hardware is included to mount the plate to most any 1 to 1½ HP router. The center
(small) ring accepts a standard Porter Cable size guide bushing. The plate fits the
following routers: Porter Cable - 100, 690, 890, 7529, 8529 series, Dewalt - DW625,
DW616, DW18 series Makita - 1100 series, Hitachi - M12VC series, Bosch - 1617,
1618, 1619 and 1619 EVS routers.
1060 ................................................................................................................................................. $29.99
Router Accessories
Bushing Centering Pin
Pre-drilled for most any router, this
plate also includes a smartly designed
centering pin that centers the guide to
the router collet. Install a Porter-Cable
style guide bushing (not included), use
the centering pin to line-up the base
plate to the collet, install your bit for
perfect alignment. Plate has a 1-3/8"
dia. center hole that will accept our in-
lay or template guide kit.
1051 ....................................................$19.99
Router Base Plate with Centering Pin
WOODWORKINGTOOLSANDACCESSORIES
Router Base Plate Replacement Screws
Aluminum Universal Router Base Plate
The uniquely designed bushing guide
centering pin works with 1/4" or 1/2"
shank router collets. Chuck the straight
end into router collet, and raise the
bushing guide until it centers on the
tapered edges of the centering pin to
align the base plate to the collet. The cen-
ter pinisa positioningdeviceonlyand isnottobe used
onanyrunningmachinery
2908 ........................................................ $7.99
No need to try and figure out what size
screw you need for your router base
plate. This set gives you the 6 most
common thread sizes for old and new
routers and fit most of the popular
models. Each size is bagged in packs of
4 and labeled. The screws can be short-
ened as needed. The six sizes that are
included in this convenient set are as
follows: 4 each 8-32 x ¾”, 4 each 10-24 x
¾”, 4 each 10-32 x ¾”, 4 each 4mm x ¾”
, 4 each 5mm x ¾”and 4 each 6mm x ¾”
Universal Centering Pin
Use our Universal Centering Pin to
center or square your router over your
work piece or check for "run-out" or
vibration in your router. The Centering
Pin is double-ended for both 1/4" and
1/2" routers. Note: This Centering Pin is
a positioning device only. It is not to be
run on any machinery of any kind.
2915 ...................................................... $5.99
3881 1 each 5/16" O.D. X 1/4" I.D. Guide Bushing......................................................... $6.99
3882 1 each 3⁄8" O.D. X 9⁄32" I.D. Guide Bushing..........................................................................$6.99
3883 1 each 7⁄16" O.D. X 11⁄32" I.D. Guide Bushing........................................................................$6.99
3884 1 each ½" O.D. X 13⁄32" I.D. Guide Bushing.........................................................................$6.99
3885 1 each 5⁄8" O.D. X 17⁄32" I.D. Guide Bushing.........................................................................$6.99
3886 1 each ¾" O.D. X 21⁄32" I.D. Guide Bushing.........................................................................$6.99
3887 1 each 51⁄64" O.D. X 5⁄8" I.D. Guide Bushing........................................................................$6.99
3888 1 each 1" O.D. X 7⁄8" I.D. Guide Bushing............................................................................ $6.99
3889 Lock Ring for Guide Bushing(s)............................................................................................... $3.99
Individual Router Guide Bushings
Upgrade your router
guide bushings.
By closing up the opening in the base of your router tomatch the diameter of small-
er bits, you will reduce the risk of getting small pieces of wood between the bit and
the plate opening. This lessens the chance of kick back while running your router.
The bushings also provide support for smaller workpieces, increase dust collection
efficiency and also help reduce tear-out. This convenient set comes with seven dif-
ferent size bushings with openings of: 5/32", 9/32", 13/32", 17/32", 21/32", 25/32",
29/32" and two locking nuts. The bushings will fit router bases or router table in-
serts with a standard 1-3/8” diameter - recessed opening that accepts template
guide bushings. Each bushing will accept a router bit that is at least 1/32” smaller
than the bushing size. Example: the 5/32”bushing will accept a 1/8”router bit.
1054 ....................................................................................................................................................................$29.99
9pc Bushing Reducer Set
1059 ....................................................................................................................................................................$34.99
Template Bushing Guide Kit
Router Bushing guides are used for following
templates for things like letter making, signs,
dovetails or most anything where patterns
or templates are used. Bushings fit router
bases or router table inserts with a standard
1-3/8” diameter - recessed opening that ac-
cepts template guide bushings. Note: You
will need a bushing lock ring (sold separately) for
proper use of these guide bushings.
This 10 piece kit is for template controlled operations such
as dovetailing, stair routing, hinge butt routing, omni-jig
template, lock face routing and other template opera-
tions. Template guides can be used directly with any router
having a base plate with a 1-3/8” dia. center hole. The kit
contains one 2-11/16”OD adapter with 4 holes (for Freud &
most Makita routers), 2 lock nuts and 7 different template
guides (5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, and 51/64”OD)
TurnLock Bushings provide fast easy guide bushing and router attachment. Use the
centering pin to install the Base Plate on most routers using a combination of pre-
drilled slots. Polycarbonate material can be modified to fit the few routers it doesn't
fit right out of the box. This set is perfect for dovetailing, sign making, and more.
Bushings included: 5/16", 3/8", 7/16", 1/2", 5/8", 51/64", and 7/16" & 5/8" Extended
Noses. Also includes an adapter for standard Porter Cable style bushings. The Turn-
Lock 9 pc Bushing only set includes 5/16", 3/8", 7/16", 1/2", 5/8", 51/64", and 7/16" &
5/8" Extended Noses. Also includes an adapter for Porter Cable style bushings
10102 Turn-Lock Base Plate & Bushings..................................................................... $24.99
10104 Turn Lock Bushings 9 PC set ............................................................................. $12.99
Milescraft Baseplate and Bushing Sets
