Router Accessories
Freud Premier 2pc Stile and Rail Set
Shaker Style
Freud Glass Panel Cabinet Door
Router Bit Set
Freud Panel Molding
25 Foot Roll
or
CreateCabinetDoorswithStubTenons
VariableExtendedTenons
5/8”
to
1-1/4”
22º
Now with Freud´s unique, patented Premier Adjustable Rail and Stile Router Bit
system, you are able to build any style of cabinet door in a range of door thick-
nesses and sizes! This extremely easy-to-use solution gives you unlimited creative
freedom, and solves the long-standing challenges & limitations of frame and panel
door construction. Rail & Stile system is the ONLY solution that allows you to:
1. Create extended tenons for extra door joint strength (patented solution)
2. Adjust groove width for different panel thicknesses
3. Choose from a variety of material thicknesses (5/8" to 1-1/4")
4. Add optional cutter to create glass or screen doors
5. Add optional cutters to create double sided profiles in thicker stock material.
3009
2 PC Premier Style and Rail Set Shaker Style 99-762 .......................................
$127.99
Creates top quality strong, tight-fitting glass panel door joints with ease & accuracy
• Extra strong rail and stile joints with a unique lock in the stile and rail joint, plus
significantly more gluing surface. No other set on the market provides this feature.
• Easy time saving set-up improves accuracy and increases profitability for the pro-
fessional.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on table-mounted portable routers.
3023
Glass Panel Cabinet Door Router Bit Set 99-286 .............................................
$186.99
Seepage110 formoredetailsonoptionaladd-ons
The easy way to install glass in cabinet doors, quickly and securely! The Freud Glass
Panel Molding stays flexible for easy installation. Simply place your door frame face
down on smooth flat surface. Carefully place the glass in the frame. With a knife or
scissors cut a miter on the end of the Plastic Panel Molding. Starting at one end,
work the molding into the frame slot. Once the end is reached, cut a matching mi-
ter. The Panel Molding fits .130" to .145" frame grooves.
3050
Freud Panel Molding 25' Roll # GM-005
.........................................................................
$19.99
# 99-286
1" 3/4"
R(1) 7/32"
R(2) 11/64"
Glass Panel Molding
Easily cut repetitive flutes to add some flair to columns, moldings, or even furniture
parts. Flutes can be very eye catching additions to most any project, but they can
also be very trying at times. Our fluting jig makes it simple by allowing you to rout
clean, evenly spaced flutes every single time. Built in rails under the jig keep the jig
level, allowing it to slide along your work piece that can be up to 8”in width. Mount
your router to the acrylic base that comes with the jig. Once mounted, the router
slides laterally on the jig to rout out as many flutes as you need!
2969
....................................................................................................................................................................
$69.99
Router Fluting Jig
Coping Sled
When making difficult narrow cross-grain rail cuts, the coping sled jig holds your
material in place. Align your material flush with the edge of the sled and clamp
it into place with the toggle clamp. Abrasive strips mounted to the base hold the
piece in place. Run the jig along your fence until you cut through the HDPE plastic
block, this creates a zero clearance, which prevents tear out. Large Toggle with 500
lbs of holding pressure secures stock. A friction strip resists stock movement. Ergo-
nomic handle provides comfort & control during the cutting process.
2936
coping sled ...............................................................................................................
$59.99
2937
HDPE blocks (2 pack).............................................................................................
$14.99
Kreg® Precision Beaded Face Frame System
Beaded Face-Frames are a great way to add detail, richness, and value to your fine
cabinetry work. The Precision Beaded Face-Frame System works in conjunction
with your router table to serve as the fastest, easiest, and most affordable way to
build beaded face-frames in a home shop.Through a process of precise notching of
rails and stiles, the Precision Beaded Face-Frame Systemsimplifies standard beaded
face-frame construction by eliminating the need to make intricate cuts on a table
saw, fit and refit miters, or spend thousands of dollars on a large specialized ma-
chine. The result is higher quality, consistent results, in less time than before.
8922
Kreg Beaded Face Frame System ..........................................................................
$379.99
9150
(A) ¼" x 1½" Notch Cutter...........................................................................................
$54.99
9151
(B) ¼" x 2" Notch Cutter...............................................................................................
$59.99
9152
(C) 3⁄8" x 1½" Notch Cutter...........................................................................................
$54.99
9153
(D) 3⁄8" x 2" Notch Cutter ..............................................................................................
$59.99
9154
(E) ¼" Standard Bead Cutter......................................................................................
$34.99
9155
(F) 5⁄16" Standard Bead Cutter.....................................................................................
$34.99
9156
(G) 3⁄8" Standard Bead Cutter .....................................................................................
$34.99
E
F
G
A
B C
D
Beaded Face Frame System
Router
Bits
Includes:
Heavy Duty Aluminum Fence
Zero Clearance Sliding Base
Integrated Clamp
Router Table Stop
¼" x 1½" Notching Bit (9150)
¼" Beading Bit (9154)
RouterTable Set-up Bar
Instructional DVD
Integrated Tape Measure
½" Dowel Pin
