Router Jigs &Templates
Accessories
Precision Joinery System
Templates
™
™
™
Heart Wave
Heart
Lock
Hexagon
New Arrowhead 8˚ Through Dovetail Dogbone
Butterfly
Top Hat
Large Key
Arrowhead
Half Blind
Through Dovetail Key
Bread Box
Bird's Eye Kings Crown
Lolli-pop
Wave
Teddy Bear
Optional
Original Fast Joint™ Templates
Creating unprecedented joint designs with your Fast-joint™ system has never
been easier. We designed this unique joint system with matching templates.
Setting up your joints is as easy as putting a router bit into the router, installing
the guide bushing and setting the height of your bit. To create a joint all you
have to do is install the male template on one side of the jig platform and then
install the female template on the other side. The hardest part about the Fast-
joint™ System is choosing what type of joint you want to make. This system has
everything you need to get started making projects that will stand out above
the rest. Please Note: this system is designed for table mounted routers only.
The Fast-joint™ jig systemwill handle stock up to 14" wide and ¼" to ¾" thick.
The Fast-Joint adapter plate is for routers
that do not accept template guide bush-
ings. Install the guide bushing on to the adapter
plate. With the power off, place the adapter plate
on top of your router table, center the bushing guide
over your spiral bit, and clamp the adapter plate to your router table. Now your
ready to start using your fast joint system! Made from 3/8" thick PVC material,
to provide durability and hold it's flatness. The adapter plate measures 16" x 24"
which fits most any router table top.
3588 Fast-joint™ adapter plate .......................................................................................$24.99
The standard and tight guide bushings are the two
most commonly used bushings when using the Fast
Joint system. Each bushing is clearly marked "standard"
and "tight" respectively for easy identification which
eliminates any guesswork. The standard bushing is
used for most fast joint operations, however if you need
a tighter fit on particular joints - use the "tight" bushing. The standard bushing
has an opening of .308 O.D. and the tight bushing has an opening of .311 O.D.
3492 standard guide bushing.......................................................................................................$5.99
3493 tight guide bushing................................................................................................................$5.99
3425 loose guide bushing...............................................................................................................$5.99
3471 Half Blind dovetail 2pc ........................................................................................... $17.99
3472 * Through dovetail / tail 1pc (for 3⁄8"stock only) ......................................................... $7.99
3473 Heart template 2pc ................................................................................................. $17.99
3474 Key template 2pc . ...................................................................................................$17.99
3475 Heart Wave template 2pc ..................................................................................... $17.99
3476 Large Key template 2pc .........................................................................................$17.99
3477 Lock template 2pc ................................................................................................... $17.99
3478 Wave template 2pc ................................................................................................. $17.99
3479 Lollipop template 2pc ........................................................................................... $17.99
3480 Arrowhead template 2pc.......................................................................................$17.99
3481 Teddy Bear template 2pc ......................................................................................$17.99
3498 ButterflyWing template 2pc.......................................................................................$17.99
3496 Hexagon template 2pc..................................................................................................$17.99
3494 Top Hat template 2pc.....................................................................................................$17.99
3495 Bread Box template 2pc................................................................................................$17.99
3497 New Arrowhead template 2pc...................................................................................$17.99
3490 Dogbone template 2pc.................................................................................................$19.99
3586 *8˚ Through dovetail / tail 1pc with 8˚ dovetail bit (for ½"to ¾" stock)...............$34.99
3491 Kings Crown template 2pc ..........................................................................................$17.99
3483 Bird's eye template 2pc.................................................................................................$17.99
3470 Fast-joint™ precision joinery system includes:
1 Ea. Fast-joint™ aluminum jig platformwith all the necessary hardware....$74.99
3 Ea. Toggle Clamps ............................................................................................................$29.99
1 Ea. Standard Bushing .308 O.D. ....................................................................................$5.99
1 Ea. Tighter Fit Bushing .311 O.D. ...................................................................................$5.99
1 Ea Dovetail Bushing .4375 O.D. 7/16”........................................................................$5.99
1 Ea. spring lock washer for bushing ..............................................................................$2.50
1 Ea. Half blind Dovetail Set ............................................................................................$17.99
1 Ea. Heart Template Set ...................................................................................................$17.99
1 Ea. Key Template Set .......................................................................................................$17.99
1 Ea. Through Dovetail / Tail Template ...........................................................................$7.99
1 Ea. 3/16 up cut spiral router bit ..................................................................................$14.99
1 Ea. 14° Dovetail bit ...........................................................................................................$16.99
1 Ea. Brass Centering Pin .....................................................................................................$8.99
2 Ea. Spring Clamps ...............................................................................................................$1.99
1 Ea. 3/8”x 3/8”brass set up bar .......................................................................................$3.99
If purchased separately $234.36
3470 Fast-joint™ precision joinery system (listed above)................................... $169.99
3467 Fast-joint™ Deluxe systemwith the 11 original templates ................... $269.99
3595 Fast-joint™ Master systemwith all 20 templates ....................................... $399.99
3482 3/16" up-cut spiral Fastjoint™ replacement bit .............................................$14.99
4017 Fast Joint Instructional DVD ..................................................................................$14.99
* Through dovetail template works with half blind template set
9 additional Fast Joint™ Templates
Adapter Plate
Guide Bushings
Create joints like these
3-D
Heart
Half Blind
Dovetail
End to End
Dovetail
Recessed Heart
WIth the Fast-joint™ we have made it easy to
make great looking joints with our pre-milled
granular PVC templates. Each template is 3/8"
thick and clearly labeled male or female for easy
identification. All of our templates have a full
lifetime warranty, which means we will replace
them no matter what! Even if you run into the
template with your router, we will replace it. Be-
low are all of our unique templates, including 9
new templates that we know you'll enjoy.
