89 / 208
Your One Stop Supply Shop”
89
Sawblades & Dados
Have a table saw blade that
won’t fit correctly? These preci-
sion bushings are designed for
reducing arbor size of Freud and
other manufactured sawblades
from 1” to 5/8”.
Dimensions: (diagram
to the left) d= 5/8”bore, D= 1”andT=.080”
2315
......................................................................................
$3.99
When making a precision cut, any
amount of vibration can mean
the difference between a mas-
terpiece or scrap. This set of saw
blade stabilizers are precisionma-
chined, and balanced to provide
extra stability on your blade.
Dimensions: (diagram to the left) d= 5/8”bore, D= 3-1/2”andT=3/32”
2313
....................................................................................
$19.97
Premier Fusion Blade
This blade is the most technologically ad-
vanced blade on the market! It will
give you the smoothest, cleanest
cuts that you’ve ever seen from
a general purpose blade! This
blade provides superior per-
formance in both cross cut-
ting and ripping.
2318
10”x40Tx1/8“Kerfx5/8”Arbor ...................................
$99.99
2263
10”x40Tx3/32“Kerfx5/8”Arbor .................................
$79.99
Plexi-Glass / Plastics LU94M
Acrylic, poly-carbonate, vinyl and most
other plastics can now be cut cleanly
without melting using the LU94M
series from Freud. By Combining
MicroGrain carbide tips with a
specially modified triple chip
grind and a negative hook
angle.
2291
10”x80Tx3/32”Kerf x 5/8”Arbor ................................
$87.99
Thin Non-Ferrous Metal LU90M
Designed specifically to cut thin, nonfer-
rous metal extrusions such as aluminum
storm window frames without dam-
aging the delicate profiles.The high
number of specially formulated
MicroGrain carbide tips and the
slightly positive hook angle al-
low these blades to slice quickly
.
2287
10”x100Tx3/32“ThinKerfx5/8 .................................
$104.99
Ultimate Plywood LU80R
2272
10”x80Tx1/8“Kerfx5/8”Arbor ...................................
$94.99
Solid Surface LU95R
2292
10”x72Tx1/8“Kerfx5/8”Arbor .................................
$126.99
This blade features teeth with a spe-
cially designed triple chip grind
for leaving swirl-free cuts in sol-
id surface materials such as
Dupont® Corian®, Wilsonart
Gibralter® and SSV Foun-
tainhead®. With this solid
surface blades there is no
need for stabilizers.
12”Combination LU84R
Industrial Perma-SHIELD Coated Com-
bination Blade. This 1/8” kerf saw
blade for anyone that needs
good quality cuts in most any
material without changing
saw blades. Cuts well in:
hardwoods,
softwoods,
chip board and plywood.
2281
12”x60Tx1/8“Kerf x1”Arbor .....................................
$109.99
Dial-A-Width Dado
Freud’s Dial-A-Width Dado Set is a stacked dado set,
but the shims have been replaced with a patented
dial system, which allows users to adjust the width of
cut via a dial hub capable of micro adjustments. Each
“click” of the dial adjusts the blade by .004”; with an
adjustable width range of just under ¼”to 29/32”. This
dado is the only dado available that cut's true 1/4" ply-
wood dadoes. It comes with 5 chippers (4 at 1/8”and 1
at 3/32”).When combined with the 3/32”chippers, the
hub ensures a super precise fit-even on undersized
plywood. The carbide is designed and manufactured
specifically by Freud for splinter-free, flat bottom
grooves in a variety of stock.
2308
SD 606 - 6”dial-a-width dado set ..............
$234.99
2309
SD 608 - 8”dial-a-width dado set ..............
$274.99
Super Dado
The SD500 Series dadoes are the first dadoes to in-
clude a 3/32” thick chipper. This allows the cut width
to be adjusted in 1/32” increments and doubles the
number of slot widths available. Many plywoods are
being manufactured 1/32”undersized from the nomi-
nal size and this allows you to cut dadoes that will fit
these materials with less shimming. We have also in-
cluded a 6pc shim.
2306
SD 506 - 6”super dado set ...........................
$183.99
2307
SD 508 - 8”super dado set ...........................
$199.99
Stacked Dado
Freud’s quality and Craftsmanship in a stack dado,
but at a wobble dado price! The negative hook angle
makes flat bottom grooves and virtually splinter-free
cuts. It has 2 outside blades and 5-2 wing chippers. All
blades and chippers come with Freud’s kickback re-
ducing design. Perfect for the weekend woodworker
who wants an economically priced dado without sac-
rificing quality. This re-sharpenable set will produce
grooves from 1/4”to 13/16”in 1/16”increments.
2304
SD 206 - 6”stacked dado set .........................
$86.99
2305
SD 208 - 8”stacked dado set .........................
$99.99
Dado Shims
These shims allow you to adjust your
kerf width by as little as .004” incre-
ments. These shim sets are included
with all Freud Super Dadoes.
4 each .004” x 3 1/8”dia. shims
2 each .008” x 3 1/8”dia. shims
2 each .012”x 3 1/8”dia. shims
2 each .020”x 3 1/8”dia. shims.
2311
....................................................................................
$13.99
Box Joint Set
Freud has developed a method of creating perfectly
square, flat-bottom box joints, on a table saw without
using a Dado Set or saw blade. The SBOX8 Box Joint
Cutter Set makes box joint construction easy, produc-
ing, strong, accurate joints without shims or awkward
adjustments. This patent-pending innovation enables
users to produce perfectly square, precise box joints
quickly and cleanly the very first time-and every time.
The set includes instructions for making box joints and
building a box joint jig. The set cuts 1/4” and 3/8” box
joint slots. Use on all table saws for cutting grooves to
create box joints in softwood or hardwood.
2310
....................................................................................
$94.99
Table Saw Calibration Disc
These Calibration and Sanding Disks are a real time
saver for aligning your saw. Precision machined for
absolute balance and flatness. Mount these in place
of your blade and use the flat surfaces to accurately
align your saw for the best cut. Apply our self-adhesive
sanding disks and turn your table or radial arm saw
into a disk sander. Use on any table saw, radial arm
saw or miter saw.
2312
....................................................................................
$31.97
T
d
D
Saw Blade Stabilizer
T
d
D
Saw Blade Bushing
This is a Hi-ATB industrial ultra finish
saw blade with a 5/8” arbor. The
Hi-ATB tooth design gives vir-
tually chip-free, flawless fin-
ishes in veneered plywood,
melamines and laminates.
This blade replaces Freud’s
F810 un-coated blade.
Square, flat-
bottom box
joints on your
table saw
