The Deluxe Router Table fence kit has two MDF fence
plates supported by a solid aluminum "L" fence with
built in track comfortably accommodates router bits
up to 3-1/2”in diameter and comes with all the neces-
sary parts for quick and simple assembly. The system
is also equipped with a dust port that envelopes the
opening between the two MDF fence sections. The
mounting fence has a unique shim system; each side
of the fence can be shimmed with an aluminum bar
(included) that is inserted into offset tracks of varying
depth, which in turn nudges your fence forward to
the desired depth. Tall adjustment knobs allow easy
access for moving your fence forward and backward.
This system is available in a 24" or 32" length. Table not
included.
3318
**
24" deluxe fence system
..............................
$84.99
3319
**
32" deluxe fence system ...........................
$109.99
Supreme Fence Kit
Deluxe Fence System
Our Fence kit works on any table top with a center
mount router plate system. The fence is made of
solid MDF that has Mini-T-Track built in for mount-
ing featherboards and stop blocks on the front of the
fence, as well as a back side mini-T-track for mounting
to the aluminum “L” fence (included). Fence will com-
fortably accommodate bits up to 3-1/2” in diameter.
The fence comes with all the necessary parts for quick
and simple assembly.The system is also equippedwith
the handy dust port that envelopes the opening be-
tween the two MDF fence sections. A removable dust
port system allows you to attach a 2-1/2” Shop-Vac®
hose directly to the back of the fence. This fence sys-
tem can be clamped to your table with standard C-
clamps (not included).
Our Supreme Fence Kit works on any table top with
a center mount router plate system and offers great
versatility. The aluminum extrusion with UHMW in-
serts adds excellent stability when running your stock
through the cutter. The slick surface of the UHMW
inserts allow for easy feed across the fence face. The
inserts are replaceable and also allow for zero clear-
ance profile cuts. The fence also features a split design,
allowing for easy off setting of the fence (with shims).
Fence will comfortably accommodate bits up to 3-1/2”
in diameter.Threemini-T-tracks in the extrusion (which
accept 1/4” x 20 hex head bolts) allow you to attach
stop blocks, featherboards and many other jigs and
fixtures to this system. This fence system can also be
clamped to your table with C-clamps (not included).
Table top NOT included.
Table top NOT included.
24" shown
Fence Kit
1098
**
32”pre-drilled aluminum fence ...................
$29.99
1093
1 pair MDF 16”fence sections ..........................
$39.99
1141
1 pair of dust port mounting blocks.................
$4.99
0387
1ea. router dust port...............................................
$3.99
1136
1ea. small plastic featherboard...........................
$6.99
1107
1ea. fence stop block.............................................
$6.99
0987
6 ea.
¼
”x20 knob and bolts .................................
$7.50
1072
router fence kit
..........................................
$84.99
Ifyoupurchasetheseitemsseparately
..........................
$100.44
Table top NOT included.
Ifyoupurchasetheseitemsseparately
..........................
$130.44
1098
**
32”pre-drilled aluminum fence ...................
$29.99
1111
1 pair alum. 16”fence sections ........................
$69.99
1141
1 pair of dust port mounting blocks.................
$4.99
0387
1ea. router dust port...............................................
$3.99
1136
1ea. small plastic featherboard...........................
$6.99
1108
1ea. Uni-fence stop block....................................
$6.99
0987
6 ea.
¼
”x20 knob and bolts.................................
$7.50
1073
Supreme router fence kit
....................
$119.99
Uni-T-Fence Sections
MDF Router Table Fence Sections
MDF Fence Sections are 1”thick x 4”high x 15 1/2” long
(each fence section)
. and come
in a pair to be used with our Aluminum“L“Fence or any shop made sub fence. The
Mini T-Track mounted on the front and back allow for the use of many add on ac-
cessories, like stop blocks and featherboards. Aluminum "L" fence is not included.
1093
.....................................................................................................................................
$39.99
The 16” Uni-T-fence sections come in a pair that can be used with our “L “Fence or
any shopmade sub fence.True versatility with theMiniT-Track mounted on the top
(2 tracks) and front (1 track) of the fence, which allows for the use of many add on
items, such as: featherboards, stop blocks and more. The UHMW insert fences are
replaceable, & sacrificial, so you can make zero clearance cut outs for any router bit.
Aluminum "L" fence is not included.
1111
1 pair of 16” Uni-T-Fence sections....................................................................
$69.99
Side View
Side View
**distancebetweenfencemountis21-1/2"betweencenters
Router Table Fences
1094 (A)
24” "L" fence - no holes..................
$17.99
1095 (A)
32” "L" fence - no holes..................
$22.99
1096 (A)
48” "L" fence - no holes..................
$34.99
1097 (B)
24” pre drilled "L" fence .................
$24.99
• 3/8”slots milled on 9”centers
• ideal for drill press fence
1063 (C)
24”pre milled/drilled "L" fence....
$24.99
• 3/8”slots milled on 9”centers
• 3-1/2”W x 1-1/2”D milled center hole
• ideal for 24”router table fence
1098 (C)
32”pre milled/drilled "L" fence....
$29.99
• 1/4”slots milled on 21½”centers
• 3-1/2”W x 1-1/2”D milled center hole
• ideal for 32”router table fence
Fence Styles
A
Customize to your needs
B
Ideal for drill press table fences
C
Ideal for router table fences
Aluminum“L” Fences
The Aluminum “L” Fence is a
solid piece of extruded alu-
minum that can be used for
many different fence systems
like router tables, drill press
tables and bandsaw tables.
Mount independent fence
sections
(not included)
to cre-
ate one "solid" fence, this al-
lows you to slide and shim the
fence sections. The "L" fence is
available pre-drilled or solid in
various sizes. Fences can be
clamped to any table surface.
Pre-drilled fences can mount
to T-tracks with knobs and
bolts
(not included)
.
3/16”
3”
2”
Pleasenote:Dimensionsmayslightlyvary
B
A
C
