Low-Profile Bench Dogs
The low profile bench dogs fit into ¾" holes on work-
benches to create a stop on the opposite end of your
vise. Ideal for sanding, planing & more. The low profile
lets you work standard ½" or thicker stock without
getting in the way of your tool. The bench dogs with
wide jaws attached exceeds 4 square inches of pres-
sure, which virtually eliminates any marking of the
wood. The jaws slide over the top of the bench dogs
and are fastened by 2 screws which are included. The
low profile set comes with 4 bench dogs, the wide jaw
set comes with 4 lowprofile bench dogs & 4wide jaws.
1534 bench dogs (4 pack) ............................................$4.99
1535 bench dogs /wide jaws (8 pc pack) .............$12.99
Ideal for
rough panel
work
Small
Workbench
Vise
1" diameter x 10" long screw x 3/4"
diameter guide rod
13/16" diameter x 15-1/2" long screw x
3/4" diameter guide rods and 10-
1/4"wide x 19-1/4" long vise assembly
19" long x 10-1/2" wide, which will result
in a 10-1/2" clamping capacity when
mounted with a 1" wood jaw
Large
Workbench
Vise
Quick Release
Front
Vise
Quick Release
Bench
Vise
The aluminum round bench dogs are perfect for hold-
ing your stock in place on your workbench for many
different types of applications. Use them to hold your
stock for sanding, drilling, carving and more. Each
bench dog has a spring clip on the side to keep a snug,
firm fit in any 3/4" round workbench hole. The bench
dogs measure 4-3/8" in length.
Aluminum Round Bench Dogs
0671 2 ea. aluminum round bench dogs............ $13.99
Clamps
Standard Small Workbench Vise. This
vise is made from rugged castings and
precision parts that make these vises
not only economically priced, but a
great value as well. Handle is not in-
cluded with the vise. Dimensions: 1" di-
ameter x 10" long screw x 3/4" diameter
guide rods and 9" wide x 13" long vise
assembly
2960 small front vise..........................$69.99
Standard Large Workbench Vise. This
vise is made from rugged castings and
precision parts that make these vises
not only economically priced, but a
great value as well. Handle is not includ-
ed with the vise. Dimensions: 13/16" di-
ameter x 15½" long screw x 3/4" diam-
eter guide rods and 10¼"wide x 19¼"
long vise assembly
2961 large front vise..........................$89.99
Workbench Vises
Made from cast iron for accurately ma-
chined housings that provide smooth
action when in use. The main screw
is made from steel and has buttress
threads for smooth adjustments. The
unit features an adjustable front dog
which allows you to clamp larger stock
using bench dogs. Opening depth of
10" & 9" wide.
2959 quick release bench vise... $119.99
This heavy duty vise has a steel quick
release pivoting nut that allows you to
quickly slide the 1" main screw in or
out to clamp or release stock. Two 3/4"
dia. solid steel guide rods provide resis-
tance to racking The vise is 19" long x
10-1/2" wide, which will result in a 10-
1/2" clamping capacity when mounted
with a 1" wood jaw (not included).
2962 quick release front vise..........$99.99
Kreg® Bench Dogs
These simple 3/4” reinforced nylon Bench Dogs will
help make your next project easier. Included with
each Bench Dog is a solid rubber Bench Brake that
can be placed on top of the Bench Dog™ for a solid,
non-slip work surface – perfect for routing and sand-
ing.
9148 Kreg Bench Dog 4 pack.........................................$7.99
Drive a Pinch dog into an end grain along a wooden
joint, doing this allows the steel tapered pinch dog
clamps to draw boards tightly together for gluing up
panels, table bench tops and more. You can use the
Pinch Dogs repeatedly without the worry of them
twisting, bending or breaking. Use them to square
corners overs legs and the Pinch Dogs can also be
used for column assembly.
Pinch Dogs
0801 1-1/2" Pinch Dog 10 pack................................$19.99
0802 2" Pinch Dog 10 pack .......................................$20.99
12" Deep Throat C-Clamp
The deep throat C-clamp features a 4" jaw opening
with a 12" throat depth to provide greater reach on
smaller, lighter projects. Works great for clamping ve-
neers, dish or bowl laminations and more. Made from
malleable steel and has a powder coat finish for added
durability and longevity.
0739 ....................................................................................$14.99
NEW
The Clamp Vise is fast & easy clamping, just squeeze
& release. Up to 350lbs of pressure. The 3⁄4”reinforced
nylon bench dogs help make your next project easier:
Bench Brakes™ - Press in place for a non-slip work sur-
face. Includes: Bench Clamp™, Clamp Vise Plate, (2)
Blocks™, (2) Bench Dogs, (2) Bench Brakes & Hardware.
4851 Kreg Clamp Vise Kit............................................$59.99
Kreg® Clamp Vise System
