Application:
Trimming laminate
counter tops and doing
pattern work.
Downshear cutting angle produces a slic-
ing action for chip-free, splinter-free cuts
on the top surface of laminates and ve-
neers. The shear action also delivers easier,
smooth cuts in thick materials. The 3/4”di-
ameter body and full 1”or 2”cutting length
provide the stability and cutting capacity for thick
stock or for routingmultiple parts with a template. Use
in hand-held or table mounted routers. Cuts all com-
positions of wood.
Router Bits
Bearing Flush Trim Bits
Top Bearing Flush Trim Bits
Application:
Template work and
lettering
The top mounted bearings on these
bits make them ideal for lettering and
other template work where the work
piece is being grooved or routed out.
Cuts all composition materials, ply-
woods, hardwoods, and softwoods. Use on hand-held
and table-mounted portable routers.
Application:
Trimming laminate counter tops and
doing pattern work
These are the bits to rely on for a
smooth, burn-free cut. Two flutes pro-
vide faster cutting and three flutes yield
a superior finish. Cuts all composition materials, ply-
woods, hardwoods, and softwoods. Use on portable or
table-mounted routers.
Cat # Freud # D B h Flutes A H Price
2652
42-080 7/8" 7/8" 1"
2 1/4" 3"
$30.99
2653
42-090 3/4" 3/4" 1"
2 1/4"2-15/16"
$27.99
2654
42-100 3/8" 3/8" 1"
2 1/4"2-13/16"
$16.99
2655
42-102 3/8" 3/8" 1/2" 2 1/4"2-13/32"
$17.99
2656
42-104 1/2" 1/2" 1"
2 1/4"2-13/16"
$16.99
2657
42-106 1/2" 1/2" 1/2" 2 1/4" 2-1/8"
$17.99
2658
42-108 1/2" 1/2" 1"
2 3/8"2-15/16"
$19.99
2659
42-109 1/2" 1/2" 1/2" 2 1/2" 2-7/8"
$17.99
2660
42-110 1/2" 1/2" 1"
2 1/2" 3-1/4"
$18.99
2661
42-114 1/2" 1/2" 1-1/2" 2 1/2" 3-5/8"
$20.99
2662
42-116 1/2" 1/2" 2"
2 1/2" 4-3/8"
$29.99
2663
42-118 3/4" 3/4" 1"
2 1/2" 3-1/4"
$23.99
2664
44-100 1/2" 1/2" 1"
3 1/4"2-13/16"
$26.99
2665
44-102 1/2" 1/2" 1/2" 3 1/4" 2-1/8"
$24.99
2666
44-104 1/2" 1/2" 1"
3 1/2" 3-1/4"
$26.99
2667
44-108 1/2" 1/2" 1-1/2" 3 1/2" 3-5/8"
$38.99
®
A
D
h
H
B
Cat # Freud # D B h A H Price
2671
50-098 5/16" 1/2"
1" 1/4" 2-23/32"
$27.99
2672
50-101 1/2" 1/2" 1-1/4" 1/4" 2-1/2"
$30.99
2673
50-102 1/2" 1/2"
1" 1/4" 2-5/8"
$22.99
2674
50-103 5/8" 5/8" 9/16" 1/4" 2-1/4"
$25.99
2675
50-104 5/8" 5/8"
1" 1/4" 2-5/8"
$26.99
2676
50-105 9/16" 9/16" 3/4" 1/4" 2-5/16"
$30.99
2677
50-106 3/4" 3/4"
1" 1/4" 2-5/8"
$27.99
2678
50-107 9/16" 5/8" 9/16" 1/4" 2-5/16"
$27.99
2679
50-112 1"
1"
1" 1/2" 2-3/4"
$31.99
2681
50-122 1-1/8" 1-1/8" 1-1/2" 1/2" 3-3/8"
$56.99
2682
50-126 1-1/4" 1-1/4" 1-1/2" 1/2" 3-3/8"
$58.99
2683
50-130 1-1/2" 1-1/2" 1-3/4" 1/2" 3-3/4"
$69.99
2684
50-138 2"
2"
2" 1/2" 4"
$110.99
®
A
D
h
H
B
Cat # Freud # D
h
A
H Price
2718
75-100 1/8"
1/2"
1/4""
2"
$20.99
2719
75-101 3/16" 3/4"
1/4"
2"
$20.99
2720
75-102 1/4"
1"
1/4" 2-1/2"
$24.99
2721
75-103 1/4"
3/4"
1/4"
2"
$19.99
2722
75-104 5/16"
1"
1/2"
3"
$53.99
2723
75-106 3/8" 1-1/4" 1/2"
3"
$51.99
2724
75-108 1/2" 1-1/4" 1/2"
3"
$67.99
2725
75-109 1/2"
2"
1/2"
4"
$78.99
Up Spiral Bits
Down Spiral Bits
A
D
H
h
Application:
Cutting mortises and routing deep
blind holes
Freud’s solid carbide up spiral bits
combine effective chip removal with
a cut that can’t be matched by stan-
dard straight bits. Ideal for production
settings. Excellent for grooves and
dadoes in all composite materials,
plywoods, hardwoods and softwoods.
Application:
Grooves and dadoes in single-sided
veneers and laminates
Freud’s solid carbide down spiral bits
are ideal for smooth, chip-free rout-
ing where chip removal is not a prob-
lem. Cuts all composition materials,
plywoods, hard, and softwoods.
Cat # Freud # D
h
A
H Price
2729
76-100 1/8"
1/2"
1/4"
2"
$21.99
2730
76-101 3/16" 3/4"
1/4"
2"
$20.99
2731
76-102 1/4"
1"
1/4" 2-1/2"
$22.99
2732
76-103 1/4"
3/4"
1/4"
2"
$19.99
2733
76-104 5/16"
1"
1/2" 2-1/2"
$55.99
2734
76-106 3/8" 1-1/4" 1/2'
3"
$50.99
2735
76-108 1/2" 1-1/4" 1/2"
3"
$57.99
2736
76-109 1/2" 1-1/2" 1/2" 3-1/2"
$61.99
2737
76-110 1/2"
2"
1/2"
4"
$89.99
®
A
H
D
®
Top & Bottom Flush Trim Bits
Flush Trim Upcut Spiral Bits
Flush Trim Downcut Spiral Bits
Downshear Helix
Flush Trim Bits
Application:
Trimming laminate counter tops
and doing pattern work
Double bearing design allows you to
choose the cutting direction that best
suits your work piece. Freud’s Top &
Bottom Bearing Bits let you rout half
the curve in one direction, flip the
work piece over and rout the other
half in the opposite direction with-
out repositioning your pattern. Perfect for templates
placed above or below the work piece, or to trim
laminates or veneer perfectly flush with counter tops,
shelving and other projects.
Application:
Perfect for any flush trim or pattern
application, especially in abrasive
materials like melamine or solid
surface.
Freud’s solid carbide spiral flush trim
bits feature a special TiCo™ carbide
blend that delivers extremely long life
in wood or abrasive materials. Up-cut spiral design
clears chips fast. Continuous spiral cutting action pro-
duces a super-smooth cut.
Application:
Perfect for any flush trim or pattern
application, especially in abrasive ma-
terials like melamine or solid surface.
Down-cut spiral design produces an
extra-clean top edge on delicate surfaces. Freud’s solid
carbide spiral flush trim bits feature a special TiCo™
carbide blend that delivers extremely long life in wood
or abrasive materials. Continuous spiral cutting action
produces a super-smooth cut. Use in hand-held or
table mounted routers.
Cat # Freud # D B h A H Price
2685
50-501 1/2"
1/4" 1-1/4" 1/4" 3-5/16"
$34.99
2686
50-509 3/4"
3/4" 1-5/8" 1/2" 3-7/8"
$46.99
Cat # Freud # D B h A H Price
3014
75-508 1/2"
1/2" 1-1/4" 1/2" 3-3/4"
$124.99
3015
75-509 1/2"
1/2"
2" 1/2" 4-3/4"
$142.99
Cat # Freud # D B h A H Price
3016
76-508 1/2"
1/2" 1-1/4" 1/2" 3-3/4"
$126.99
3017
76-509 1/2"
1/2"
2" 1/2" 4-3/4"
$145.99
®
A
h
H
D
Cat # Freud # D B h A H Price
3013
42-202 3/4" 3/4"
1" 1/2" 3-1/8"
$32.99
2670
42-204 3/4" 3/4"
2" 1/2" 4-1/8"
$38.99
A
D
h
H
®
B
D
h
H
A
®
1/2”
D
h
H
A
1/2”
Freud’sSuperiorTiCo™
HiDensityCarbide
Other’susestandard
genericcarbides
