Picture Frame Molding Sets
Wide Crown Molding System
Wide Crown Molding Bits
Crown molding is the perfect way to transform a room, giving height and elegance to an otherwise ordinary ceiling. But commercially manufac-
tured wide crown molding is expensive, hard to find, and the selection of available wood species is very limited. Now, thanks to Freud’s uniqueWide
Crown Molding bits, woodworkers can mill their own 5-1/2" wide Crown Molding economically and in their choice of wood and profile. These bits
are the only router tooling capable of producing such wide crown molding, they also feature a carefully designed shape that lets you mix and match
profiles to produce precisely the shape you need – up to fifteen different profiles from only six bits! Use the same bit on the top and bottom cut
(diagram left) to create matching profile molding. You can also mix and match two different molding bits to create the nine profiles shown below.
Freud’s Molding Bevel Cutter is a fast,
easy way to finish your crown molding
and ensure a perfect 38° installation for
an authentic crown molding design.
Features matched 38° and 52° cutting
edges. Rout the top edge of the mold-
ing with stock face down, then flip over to rout the bottomedge face up.Works
with all profiles in the Large Crown Molding system. Use in a router table with
fence only. The bevel molding bit measures 2-3/8" in overall diameter, carbide
height - 1-3/8", shank diameter - 1/2", and overall length is 2-13/16".
3053
bevel molding bit (99-421) ........................................................................
$80.99
Picture Frame Molding Sets
With our 3, 4 and 6 piece picture frame molding sets, you can cre-
ate hundreds of different profiles by simply mixing and matching
different router bits from these sets. Each set comes with a Free
instructional DVD and a Molding profile booklet. The booklet has
over 180 profile ideas just to get you started! We have created a
7" wide piece of crown molding (shown below) with our 6 piece
picture frame set (using bits #1 - #5). Create your own custom look
or stick with a classic style. There is hundreds more you can make.
All bits in the sets are 1/2" shanks.
Ceiling
Wall
38°
52°
1
2
1
4
1
4
3
2
3
3
4
5
2
5
5
Dentil
Molding
6
Dentil
Molding
6
Dentil
Molding
6
®
52°
38°
2-3/4”
Transition Line
2-3/4”
Transition Line
Dentil
Molding
Recess
2-3/4”
Transition Line
2-3/4”
Transition Line
2-3/4”
Transition Line
Upper Profile 1
Lower Profile 2
5-1/2”
Transition
Line
®
®
®
®
®
®
Fence
Table
Fence
Table
®
®
Remove after
routing large
profiles
Remove after
routing large
profiles
Transition
Line
Lower Profile
Upper Profile
Lower Profile
Upper Profile
Cat # Freud # Profile # Overall
Diameter
Carbide
Height
Shank
Diameter
Overall
Length Price
A1
3028
99-418 profile 5 1-1/4”
3"
1/2"
4-7/16"
$80.99
B1
3026
99-416 profile 3 1-13/32”
3"
1/2"
4-7/16"
$80.99
C1
3024
99-414 profile 1 1-5/16"
3"
1/2"
4-7/16"
$80.99
D1
3025
99-415 profile 2 1-3/8” 3-1/16"
1/2"
4-9/16"
$80.99
E1
3027
99-417 profile 4 1-3/8” 3-1/16"
1/2"
4-9/16"
$80.99
F1
3029
99-419 profile 6 1-3/8” 3-1/16"
1/2"
4-9/16"
$80.99
G1
3052
peacht 6pc set
-
-
-
-
$399.99
Nine profiles created with Freuds Wide Crown Molding Bits!
Ensure a perfect fit with the Molding Bevel Cutter
2-3/4”
Transition Line
A1
B1
C1
D1
E1
F1
3 PC Set
includes bit #1, 2 and 3, plus the instructional DVD and Molding Profile Guide.
2938
..................................................................................................................................................................................
$99.99
4 PC Set
includes bit #1, 2 , 3 and 4, plus the instructional DVD and Molding Profile Guide.
2939
................................................................................................................................................................................
$149.99
6 PC Set
includes bit #1, 2, 3, 4, 5 and 6 plus the instructional DVD and Molding Profile Guide.
2940
................................................................................................................................................................................
$229.99
Create hundreds of profiles with our Picture Frame Molding Sets
*Drawings are not to scale
®
®
Æ
®
#3
#5
#2 #1
#4
Cat #
2463
#1
#2
#3
#4
freud #
99-418
freud #
99-416
freud #
99-414
freud #
99-415
freud #
99-417
freud #
99-419
Cat #
2623
Cat #
2796
Cat #
2794
#6
Cat #
2793
#5
Cat #
2785
