Router Bits
Bevel Trim Bits
Cove Bits
Table Edge & Hand Rail Bits
Multi Profile Bits
Table Top Classical Bits
V-Grooving Bits
Slot Cutter Bits
Application:
Cutting bevels in plastic laminates
for a clean, finished edge
The 41 Series Bits provide a range of
bevels from 8 degrees to 45 degrees
and feature a ball bearing guide. The
66-100 solid carbide bit creates a 7-de-
gree bevel and includes a self-piloting
feature that eliminates the expense and upkeep of a
ball bearing assembly. Cuts all plastic laminates. Use
on Hand-held routers, table-mounted portable rout-
ers, & laminate trimmers for trimming plastic laminate.
Application:
Smooth, decorative edging
and inverted radii
Create smooth, classic cove
profiles with Freud cove bits,
which have a shear angle that
slices wood similar to the way
a craftsman uses a hand plane. Cuts all composition
materials, plywoods, hardwoods, and softwoods. Use
on hand-held and table-mounted portable routers.
Application:
One bit produces numerous designs
for face, corner and crown molding
Thick carbide tips and a sturdy 1/2”shank allow you to
produce countless molding profiles. Produce an end-
less number of profile designs by varying the height
and fence settings and making multiple passes.
Application:
Attractive edging of tables,
plaques and handrails
Produces sturdy, attractive
handrails for staircases. Com-
bine with another rail profile
to create a custom rail-
ing design. Use on
hand-held & table-
mounted portable
routers.
Application:
Ornamental edge for
tables and desks
Enhance the beauty of the
wood found in occasional &
dining room tables. Cuts all
composition materials, ply-
woods, hardwoods, and soft-
woods. Use on hand-held & ta-
ble-mounted portable routers.
These Freud router bits include three wing slotting
cutter, arbor and a ball bearing. Cuts all composition
materials including: plywoods, hardwoods, and soft-
woods. Use on hand-held and table-mounted porta-
ble router set-ups. Each cutter depth is 9/16".
Application:
Engraving, decorative
accents and signs
Ideal for making signs and adding
decorative accents to furniture &
plaques, Freud’s “V” grooving bits
are designed to cut deep or shallow
“V” grooves. Cuts all composition
materials, plywoods, hardwoods, &
softwoods. Use on CNC, automatic routers as well as
hand-held & table-mounted portable routers.
B
d
D
h H
®
A
Cat # Freud # D B h d A H Price
2645
41-102 19/32" 1/2" 9/32" 150 1/4" 1-7/8"
$28.99
2646
41-104 19/32" 1/2" 9/32" 250 1/4" 1-7/8”
$30.99
2648
41-108 25/32" 3/8" 29/64" 250 1/4" 1-15/16”
$31.99
2649
41-110 9/16" 1/2" 13/32" 80 1/4" 2"
$35.99
2715
66-100 1/4" 3/16" 1/4" 70 1/4" 1-1/2"
$9.99
Cat # Freud # D h R1 R2 R3 A H Price
2867
99-PK1 25/32" 159/64" 25/64" 5/16" 15/64" 1/2" 4"
$85.99
2868
99-PKJ 1-1/2" 17/64" 7/32" 3/16" 1/8" 1/2" 3"
$68.99
Cat # Freud # D B h R1 R2 A H Price
2852
99-452 25/8" 1/2" 25/32" 13/32" 11/64" 1/2" 23/4"
$101.99
Cat # Freud # D B h R1 R2 A H Price
2791
99-010 1-1/2" 1/2" 9/16" 3/8" 1/8" 1/2" 21/2"
$67.99
Cat # Freud # D h d
A H Price
2462
20-106 5/8" 1/2" 900 1/2" 2-1/4"
$28.99
2463
20-107 3/8" 1/2" 900 1/2" 2-1/4"
$22.99
2465
20-109 1/2" 1/2" 900 1/2" 2-1/4"
$29.99
2470
20-152 1/2" 1/2" 600 1/4"
2"
$30.99
Cat # Freud # D B h R A H Price
2511
30-098 5/8" 3/8" 1/2" 1/8" 1/4" 23/16"
$30.99
2517
30-107 1-3/4" 1/2" 3/4" 5/8" 1/2" 2-1/2"
$49.99
2518
30-108 2"
1/2" 7/8" 3/4" 1/2" 2-5/8"
$59.99
2520
30-110 1"
1/2" 1/2" 1/4" 1/2" 2-1/2"
$34.99
2522
30-112 1-1/4" 1/2" 1/2" 3/8" 1/2" 2-1/2"
$35.99
2523
30-114 1-1/2" 1/2" 5/8" 1/2" 1/2" 2-1/2"
$36.99
Cat # Freud # D
h
A
H Price
2708
63-156 2"
3/32" 1/2" 2-3/8"
$25.99
2709
63-158 2"
1/8"
1/2" 2-3/8"
$25.99
2710
63-159 2"
5/32" 1/2" 2-3/8"
$25.99
2711
63-160 2"
3/16" 1/2" 2-3/8"
$26.99
2713
63-162 2"
1/4"
1/2" 2-3/8"
$26.99
D
A
h
H
d
Æ
®
22mm
D
h
H
A
B
D
A
h H
R
®
A
®
h
H
D
R1
R2
B
R1
R3
B
A
®
h
H
D
R2
R2
R 1
R 2
h
H
A
B
D
Æ
3-d Examples
4
cutters
4
cutters
Application:
Producing slots and
grooves 9/16”deep
for T-moldings, Spline
Joints, Tongue &
Groove Joints, and
many other
applications
Router Bit Care
Extend the life of your tools with this industrial
strength non-toxic, biodegradable, wood resin re-
mover. Perfect for blades, bits, files, wrenches, etc
and anything that comes into contact with wood.
Provides rust and corrosion protection plus it is an
excellent lubricant. This cleaner has unique properties
for breaking the molecular bond and lifting the dirt
and debris from all surfaces as opposed to dissolving
the material like other cleaners. The Mini Brush set is
great for detail work or cleaning anything from your
sawblades or even carvings in wood. Perfect for use in
your workshop and around the house. Each brush is
approximately 7”Longwith two bristled areas.The top
area measures approximately 3/8”x 3/8”and themain
bristle area measures approximately 1-1/2” x 3/8”. The
3 piece wire brush set includes: 1 each Stainless Steel
Brush, 1 each Brass Brush and 1 each Nylon Brush
10407
Trend tool & bit cleaner
18 oz
...........................
$11.50
4224
3 pc Mini Brush Set...............................................
$4.99
Trend
Tool & Bit Cleaner
3 pc Mini
Brush Set
Foam Router Bit Trays
Keep your bits organized and protected with these
convenient foam rubber router bit trays. Holes are on
1”centers. The 12”Router Bit Tray stores and organizes
up to 100 bits, with 50 holes each for ½” & ¼” shanks.
(1/4” holes accept 8mm shanks as well.)
The tray measures 12” x
12” x 1½”. The 24” Router Bit Tray XL stores up to 220
bits, with 110 holes each for ½”& ¼”shanks.
(1/4”holesac-
cept8mmshanksaswell.)
Tray measures 24”x 12”x 1½”thick.
1044
Router Bit Tray 12”x 12”x 1½”
...............................
$14.99
1171
Router Bit Tray XL 24”x 12”x 1½”
.....................
$29.99
Router Bit Tray
12” x 12” x 1½” thick.
Fits up to 100 bits
Router Bit Tray XL
24” x 12” x 1½” thick.
Fits up to 220 bits
