Your One Stop Supply Shop”

51

Clamps

Perfect for

miter fences

and more!

Large Toggle Foot Pads

This oversized clamping foot provides more stable clamping pressure and does not

mar on soft woods.The swivel-action foot is perfect for clamping angled stock, and

measures 1-5/8" in diameter. The Swivel Toggle Foot and Bolt will fit most any style

toggle clamp. The Bolt (with foot attached) is available in two different sizes (each

in 1/4" and 3/8" tpi): 2" and 6". Height adjustment washers and hex nuts are includ-

ed.The dual pad assembly works with large toggles and offers more holding capac-

ity than standard foot pads. Fits most standard large toggles that accept 5/16”bolts.

1160

Large swivel foot for large toggle / 2" long bolt (5/16" x 18 tpi) ...................

$4.99

1161

Large swivel foot for large toggle / 6" long bolt (5/16" x 18 tpi) ...................

$5.99

1394

Large swivel foot for small toggle / 2" long bolt (1/4" x 20 tpi) .....................

$4.99

1395

Large swivel foot for small toggle / 6" long bolt (1/4" x 20 tpi) .....................

$5.99

1396

Large swivel foot for push toggles / 2" long bolt (M8 x 1.25).........................

$4.99

3413

Dual Pad Assembly for large toggles........................................................................

$9.99

Push Toggle Clamps are for keeping stock tight against fences for drilling or cut-

ting. Unmounted toggle (A) can be mounted to any jig or fixture with wood screws

(not included)

. Mounted toggle (B) works with our mini T-track

(page 78)

. Mounted

toggle (C) works with HD T-track

(page 78)

. Each toggle comes with adjustable rub-

ber pressure tips. Replacement tips are also available in 2 packs.

1149 A

large push toggle clamp.......................................................................................

$11.99

1155 B

large mounted push toggle clamp with 1/4”x20 bolt ............................

$14.99

1152 C

large mounted push toggle clamp with 3/8”x16 bolt .............................

$14.99

1156

2-1/2" replacement bolt / rubber tip 2 pack...................................................

$1.99

1157

3" replacement bolt / rubber tip 2 pack ...........................................................

$1.99

Push Toggle Clamps

Standard and Mounted Toggles

Mini Toggles

Toggles can be installed onworkbenches, fixtures andmore for setting and holding

your work. Unmounted toggles (A & D) can be mounted to any jig with screws

(not

included)

. Mounted toggles (B & E) work with mini T-track

(page 78)

. Mounted toggles

(C & F) work with HD T-track

(page 78)

. All toggles come with adjustable rubber pres-

sure tips. Replacement tips are also available in 2 packs.

1147 A

small toggle clamp ...................................................................................................

$9.99

1153 B

small mounted toggle clamp with 1/4”x20 bolt.........................................

$12.99

1150 C

small mounted toggle clamp with 3/8”x16 bolt.........................................

$12.99

1148 D

large toggle clamp .................................................................................................

$10.99

1154 E

large mounted toggle clamp with 1/4”x20 bolt .........................................

$14.99

1151 F

large mounted toggle clamp with 3/8”x16 bolt .........................................

$14.99

3414 G

small T-handle toggle clamp ..............................................................................

$10.99

3418 H

small vertical handle toggle................................................................................

$10.99

1156 I

2-1/2" replacement bolt / rubber tip

(for large toggle)

2 pack........................

$1.99

1157 J

3" replacement bolt / rubber tip

(for large toggle)

2 pack.................................

$1.99

1158 K

2-1/4" replacement bolt / rubber tip

(for small toggle)

2 pack........................

$1.99

1159 L

1-7/8" replacement bolt / rubber tip

(for small toggle)

2 pack........................

$1.99

Perfect for lighter duty projects. Once attached with wood screws

(not included)

to a

workbench or fixture the Mini Toggles provide quick holding pressure to keep your

stock in place. EachMini toggle provides approximately 110 lbs of holding pressure.

3415 A

Mini T-handle toggle clamp ..................................................................................

$9.99

3416 B

Mini Push toggle clamp.........................................................................................

$10.99

3417 C

Mini Vertical toggle clamp .....................................................................................

$9.99

3419 D

Mini Toggle Clamp ....................................................................................................

$9.99

A

A

B

B

C

C

D

E

F

I-L

H

G

A

B

C

D

Bessey Auto-Adjust Toggle Clamps

No more having to adjust your toggle clamp manually when your stock changes

thickness even slightly. Bessey’s Auto-Adjust Toggle clamps will revolutionize the

way you use toggle clamps. Unique among toggle clamps, they automatically ad-

just to different workpiece thicknesses while maintaining constant clamp pressure.

The removable non-marring plastic cap is included on the 7/8” diameter pads. A

simple screw at the base of the operating handle allows you to dial in the amount

of clamping pressure to be applied. A locking nut on the screw prevents it from

changing during use. For more detailed information about each Bessey toggle

clamp, visit our website at www.ptreeusa.com

Mini Toggle T-track Hold Down

This toggle is the perfect solution for holding light duty stock in place along a fence.

Simply attach to a T-slot track, move it into position and secure. The extra long bolt

that comes with the toggle allows you to secure objects well below the top of your

fence. The finger tightened nuts allow you to position the hold down anywhere

along your T-track. The Mini T-track Hold Down provides up to 35 pounds of pres-

sure on your stock piece and has a rubber tip to prevent scuffing or marring. The

large 2" bolt allows you to adjust vertically to compensate for different size stock.

2988

1/4" Mini Toggle

(works with miniT-track)

.......................................................................

$14.99

2987

3/8" Mini Toggle

(works with Heavy DutyT-track)

.............................................................

$14.99

9181

STC-HA20 Low Profile..........

$19.99

3252

STC-HH20 Low Profile .........

$19.99

3253

STC-HH50 Low Profile .........

$19.99

3254

STC-HH70 High Profile........

$20.99

9182

STC-HV20 Low Profile..........

$19.99

9183

STC-IHA15 Push Pull ............

$21.99

9184

STC-IHH15 Push Pull ............

$21.99

3255

STC-IHH25 Push Pull ............

$21.99

STC-HA20

STC-IHA15

STC-HH20

STC-IHH15

STC-HH70

STC-HH50

STC-IHH25

STC-HV20

Large Swivel Foot

assembly

Dual Pad

assembly
