Power Tools
Contractor Saw with 36"
Professional T-Glide Fence
Contractor Saw with 52"
Professional T-Glide Fence
Contractor Saw with 30"
Aluminum Extrusion Fence
SawStop Brake Cartridges
Contractor Dust Control Panel
Cabinet Saw Mobile Base
Overarm Dust Collection
Jobsite Cart
Dust Collector Blade Guard
SawStop Zero Clearance
• CNS175-SFA30: includes aluminum extrusion
fence & 30" rails
• Motor: 1-3/4 HP, 110-120V, 15A *User-configurable
to 220-240V, 7-1/2A
• Footprint: 25-3/4" w, 27" d
• Overall dimensions: 58-1/2" w, 40" d, 34-3/4" h
• Cast-iron table: 20" w, 27" d
• Extension wing: 12" w, 27" d
• Shipping weight (approx.): 280 lbs. without fence.
• Blade: 10" diameter, 5/8" arbor
• Blade tilt: left
• Maximum depth of cut: 3-1/8"
• Dado diameter: 8"
• Dado max. width: 13/16"
• Dust-collection port: 4" diameter
• Insert: zero-clearance lock-down insert
• Blade guard: polycarbonate, thin profile
• Riving knife/splitter: 2mm thick
• CNS175-TGP36: Includes 36" ProfessionalT-Glide
Fence System & Rails
• Motor: 1-3/4 HP, 110-120V, 15A *User-config-
urable to 220-240V, 7-1/2A
• Footprint: 25-3/4" w, 27" d
• Overall dimensions: 69-1/8" w, 45" d, 34-3/4" h
• Cast-iron table: 20" w, 27" d
• Extension wing: 12" w, 27" d
• Shipping weight (approx.): 280 lbs. without fence.
• Blade: 10" diameter, 5/8" arbor
• Blade tilt: left
• Maximum depth of cut: 3-1/8"
• Dado diameter: 8"
• Dado max. width: 13/16"
• Dust-collection port: 4" diameter
• Insert: zero-clearance lock-down insert
• Blade guard: Polycarbonate, thin profile
• Riving knife /splitter: 2mm thick
• CNS175-TGP52: Includes 52" ProfessionalT-Glide
Fence System & Rails
• Motor: 1-3/4 HP, 110-120V, 15A *User-config-
urable to 220-240V, 7-1/2A
• Footprint: 25-3/4 " w, 27" d
• Overall dimensions: 85-1/4”w, 45" d, 34-3/4 " h
• Cast- iron table: 20" w, 27" d
• Extension wing: 12"w, 27" d
• Shipping weight (approx.): 280 lbs. without fence.
• Blade: 10" diameter, 5/8" arbor
• Blade tilt: left
• Maximum depth of cut: 3-1/8"
• Dado diameter: 8"
• Dado max. width: 13/16"
• Dust-collection port: 4" diameter
• Insert: zero-clearance lock-down insert
• Blade guard: polycarbonate, thin profile
• Riving knife /splitter: 2mm thick
The SawStop Contractor Saw offers versatility and safety in the shop and stability and mobility on the jobsite. It delivers the performance
you need with the peace of mind only SawStop’s patented safety system can provide. The SawStop table saw’s unique brake design detects
hand or finger contact with the saw blade within milliseconds, instantly stopping and retracting the blade, helping to avoid serious injury. In
addition to the groundbreaking safety features, SawStop manufactures one of the most precise saws on the market.
Standard Shipping Rates Apply Plus $150.00 for
oversized and excess weight item
10476
Model CNS175-SFA30.................................
$1599.00
10485
cast iron wing ...................................................
$100.00
Standard Shipping Rates Apply Plus $150.00 for
oversized and excess weight item
10477
Model CNS175-TGP36.................................
$1799.00
10485
cast iron wing ...................................................
$100.00
Standard Shipping Rates Apply Plus $150.00 for
oversized and excess weight item
10478
Model CNS175-TGP52.................................
$1899.99
10485
cast iron wing ..................................................
$100.00
10488
..................................................................................
$49.00
10498
..............................................................................
$199.00
10496
...............................................................................
$139.00
10497
...............................................................................
$199.00
10512
..............................................................................
$199.00
10504
(A) SawStop ZCI Standard Insert.................
$39.00
10505
(B) SawStop ZCI Dado Insert ........................
$39.00
Includes:
1.75 HP Saw
30" Aluminum Fence
10" 40Tooth Blade
Two StampedWings
Blade Guard Assembly
Miter Gauge, Riving Knife
BladeWrenches And Manual
Includes:
1.75 HP Saw
36" T-Glide Fence
10" 40 Tooth Blade
Two StampedWings
Blade Guard Assembly
Miter Gauge, Riving Knife
Blade Wrenches And Manual
Includes:
1.75 HP Saw
52" T-Glide Fence
10" 40 Tooth Blade
Two StampedWings
Blade Guard Assembly
Miter Gauge, Riving Knife
BladeWrenches And Manual
(Requires dust collection
blade guardTSG-DC
- PLU# 10496 shown
below. Not compatible
with Contractor Saw 30"
rail kit CNS-SFA. )
10502
standard blade cartridge
(shown above)
.........
$69.00
10503
dado blade cartridge
(8" dados up to 13/16")
.....
$89.00
Contractor Saw Moblie Base
Sliding Crosscut Table
10483
..............................................................................
$160.00
10513
.............................................................................
$999.00
A
B
