Powermatic 15" Planer 15HH
Powermatic 14” Closed Stand
Bandsaw PWBS-14CS
Machine Specifications:
•85% Filter Efficiency
•3 blower speeds
•CFM: 547, 706 & 1,196
•50-65 decibels
•Time Setting 1-9 hours
•Remote Control
•Overload Protection
•Replace Filter Indicator
•Easy to Change Filters
•2 Filter System
•Electrostatic Outer Filter
•Disposable out Filter
•1/4 HP Motor
•Single Phase Motor
•115 Motor Voltage
•3-1/2 Amps
•33”x 25”x 13”
Machine Specifications:
•10" Blade Diameter
•5/8" Arbor Diameter
•4,300 RPMMotor
•3-1/8" Max Depth of Cut
•2-1/8" Max Depth at 45°
•13½" Max Rip Left
•50" Max Rip Right
•8" Max Dado Diameter
•13/16" Max DadoWidth
•T-Slot Miter Gauge
•Cast Iron Table Top
•4" Dust Port (O.D.)
•3 HP Motor
•Single Phase Motor
•230 Voltage
Machine Specifications:
•4,500 RPM
•2-7/8" Cutter Dia.
•74 Four Sided Inserts
•1/4" Max Depth of Cut
•1/8" Full Width Depth
•14-7/8" PlaningWidth
•6" Max Planing Thickness
•8" Min. Planing Length
•4" Dust Port
•3 HP Motor
•Single Phase
•230 Volts
8488 PM1200 Air Filtration System . . . . . . . . . . . $439.99
DropShippedItem:8488ShippingWeight65lbs.
StandardShippingRateAppliesPlus$6000
8459 PM2000 3HP 10" Cabinet Tablesaw . . . . .$3059.00
DropShippedItem:8459ShippingWeight422lbs.
FREEDROPSHIPPING
8479 14" Bandsaw PWBS-14CS . . . . . . . . . . . . . .$1199.99
DropShippedItem:8479ShippingWeight221lbs.
StandardShippingRateAppliesPlus$8500
8482 15HH 3HP Powermatic Planer . . . . . . . . . . $3059.99
DropShippedItem:8482ShippingWeight537lbs.
FREEDROPSHIPPING
Your shop may look clean, but how clean is the air?
The PM1200 Air Filtration System traps up to 99% of
all 5-micron particles and 85% of all 1-micron particles
for a healthier work environment.Three blower speeds
modify air flow. The unit can be operated either at the
cabinet or with the remote transmitter which uses
radio-frequency, eliminating the need for line-of-sight
operation. The timer has nine settings, allowing con-
tinuous operation for up to 9 hours while you’re away,
and will shut off at the end of that period. The filter
guards can be removed and installed without tools, for
instant filter access.
Machine Specifications:
•14" Wheel Diameter
•13½" Cutting CapacityWidth
•6" Cutting Capacity Height
•15" x 15" Table
•93½" Blade Length
•3/4" Max Sawblade width
•1⁄8" MinimumSawbladeWidth
•44" Table to Floor
•4" Dust Port
•1½ HP Motor
•Closed Stand
This bandsaw has a two-
piece cast iron table. A bal-
anced, nine-spoke cast iron
wheel makes for smooth
blade travel, and a Carter™
quick tension release lever
makes blade changing easy.
The helical cutter heads provide smoother cutting
and a finer finish than standard knives. The 74 four-
sided indexable carbide knife inserts do not require
adjustment after installing. Your workpiece will get
substantial support from the cast iron table. A 2-speed
gearbox features an automatic chain tensioner. The
one-piece welded steel stand has built-in lockable
casters for easy movement around the shop.
Powermatic 1 HP
PM2800B Drill Press
Powermatic PM1200
Air Filtration System
Powermatic PM2000
3HP 10" Cabinet Tablesaw
8480 1 HP PM2800B Drill Press . . . . . . . . . . . . . . $1399.99
DropShippedItem:8480ShippingWeight266lbs.
StandardShippingRateAppliesPlus$8500
Machine Specifications:
•18" Swing
•6" Spindle Travel
•Variable Spindle Speed
•0-to 90° Table Tilt
•20" x 14" Table
•24½" Chuck to table
•5/8" Chuck
•MT-2 Spindle Taper
•13-3/8" x 20" Base
•1 HP Motor
The PM2800B brings sim-
plicity to your shop. An
ease of use that is truly
unique. A level of mechan-
ical elegance that you’ll
only find in a Powermatic.
As with every product
Powermatic builds, the
PM2800B pushes the lim-
its of design, innovation,
and durability
Powermatic 3520B
Lathe
The award winning PM2000 table saw sets a new stan-
dard for innovation with an array of patented features
and massive body design. It boasts the heaviest cast
iron base in its class that virtually eliminates table vi-
bration. The cast iron tables are oversized, and the
push button arbor lock is accessible from above the
table top to eliminate the need for dual arbor wrench-
es. The quick-release riving knife design helps reduce
the chance of kickback. The blade tilt scale has adjust-
able angle indicators for repetitive bevel cuts. Built-in
retractable omni-directional caster system mobilizes
your table saw. A wide stance, heavy-duty trunnion
and concave teeth on the trunnion gears promote
easier raising and tilting of saw blade. Poly-V drive belt
system results in quieter, more efficient power transfer
from the motor to the arbor with virtually no vibration
and less heat build up. Built-in dust collection port
with sloped cabinet floor and convenient access to the
inside of the saw cabinet make for simple clean-up.
The saw has a proprietary safety switch with magnetic
interlock, and the stop button can be knee activated
Machine Specifications:
•20" Swing over bed
•16" Swing over TR Base
•34½" Between Centers
•Full Slide Headstock
•Infinite Spindle Speeds
•50-3200 RPM
•48 Indexing Positions
•3/8" Hole in Tailstock
•1¼"x8 Spindle Threads
•2 HP Motor
•Single Phase Motor
•220 Volts
•Configurable 110 / 220V
•MT-2 Spindle
8483 2HP 3520B Lathe . . . . . . . . . . . . . . . . . . . . . . .$3999.99
DropShippedItem:8483ShippingWeight454lbs.
FREEDROPSHIPPING
The 3520B retained all the features of the prior mod-
els such as the sliding headstock, electronic vari-
able speed with low and high speed ranges, and the
spindle lock. More features include: Digital RPM read-
out, built in spindle indexing on the head stock, and
a re-designed tailstock with internal storage, chrome
trimmed handwheels, and a laser etched quill which
is self ejecting. Additional features include a sliding
hammer knockout rod with brass tip, an attached tool
caddy and a metal shelf for tool storage.
