Clear acrylic
template for
easy set up
This 19” jig is set-up for pin spacing of 1-1/4” on cen-
ter, and can be adjusted for drilling either 2-1/2” or
1-15/32” from the edge. Indexing holes keep align-
ment accurate as you drill along any length board. In-
cludes self-centering 1/4” brad point bit and jig. 5mm
holes are possible just by swapping the 1/4”bit with a
5mm self centering bit (sold separately).
0853
drilling jig w/
¼
”bit.............................................
$31.99
Shelf Pin Drilling Jig
Drawer Pull Installation Jig
Mark position for drawer pulls with our “Drawer Pull
Installation Jig”. Mark center line, choose boring width
needed and position wooden guide for correct spac-
ing and lock. Align jig over center line & mark holes.
Remove jig and drill. Measures 7” wide by 6” tall. The
jig is designed for the most common boring widths:
96mm, 3”, 3¾”, 3½”, 2½”, and 4”.
0857
...................................................................................
$7.99
Woodboring Accessories
If you’re adding shelf pin holes to an existing piece of
furniture or building shelves from scratch, the Kreg
Shelf Pin Jig is the perfect tool for the job. Features
hardened steel drill guides which ensure perfectly
precise, straight drilling. It includes a dual position
adjustable fence for custom hole placement, a locat-
ing pin for quick and accurate spacing, a handy jig ex-
tender which lets you connect multiple Shelf Pin Jigs
together, and a ¼" brad-point bit with depth collar. In-
cludes: Shelf-Pin Jig, Locating Pin, Jig Extender, ¼" Drill
Bit, Depth Collar, Wrench, Four ¼" Shelf Pins.
8989
Kreg Shelf Pin Jig.................................................
$34.99
8992
Kreg 5 mm drill bit................................................
$7.99
Kreg® Shelf Pin Jig
1092
Easy Bore Jig........................................................
$179.99
EZ ALIGN Shelf Pin Jig
Sommerfeld
Easy Bore Hinge Jig
Sommerfeld
Hardware Drilling Jig
The Complete Sommerfeld
Made Easy Series DVD Set
The EZ-Align Shelf Pin Jig is a dual drilling jig that allows you to drill two rows of shelf pin holes that are perfectly
aligned! This eliminates that chance for rocking or wobbling shelves. The EZ-Align jig also provides perfect verti-
cal spacing of 1-1/4" (32mm) between pin holes.Two dual purpose star indexing pins are included tomake align-
ing of your holes a breeze. Each pin can index either 1/4" pin holes or 5mm pin holes (both the 1/4" & 5mm self
centering bits are included). The jig also features a 50mm index from opposite side of the jig for larger or wider
shelves.Works with both existing and non-assembled cabinets.The EZ-Align Shelf Pin Jig is perfect for thosewho
want to get it done right the first time.
0804
EZ ALIGN Shelf Pin Jig with 5mm & 1/4" self centering bit...................................................................................
$126.99
0851
extra 5mm self centering bit ...............................................................................................................................................
$19.99
0852
extra 1/4" self centering bit .................................................................................................................................................
$19.99
Drill your shelf pin
holes on existing
cabinets as well as
non- assembled
cabinets
Includes a 5mm and
1/4" self centering
drill bit
5mm & 1/4” Self Centering Bits
A 3/8”diameter recessed tip fits neat-
ly into shelf pin and drawer pull tem-
plate holes for a perfectly centered
bore. The bit has a smooth spring
action for easy, comfortable drilling.
Available in 5mm and 1/4”sizes.
0851
5mm self centering bit ....................................
$19.99
0852
1/4”self centering bit .......................................
$19.99
The Easy Mark drilling jig will help you align and drill
the hardware mounting holes for knobs and handles
quickly, precisely andwith absolute repeatability. And,
when you finish, all handles and knobs will be in per-
fect alignment with one another...a sight to behold! If
you’re still measuring, marking and drilling large num-
bers of mounting holes without the aid of a device like
this, you’re wasting a lot of valuable time.
Master cabinetmaker Marc Sommerfeld’s DVD’s show
you all the tips and tools that will help you build proj-
ects just like the Pros! Includes: Arched Raised Pan-
els Made Easy, Glass Panel Doors Made Easy, Router
Tables Made Easy, Cabinetmaking Made Easy, Shaker
Raised Panels Made Easy, Mini Raised Panels Made
Easy, Mitered Raised Panels Made Easy, Dovetail Made
Easy, Angle Making Made Easy, Beaded Face Frames
Made Easy, Curved Cabinets Made Easy and more!
1091
Easy Mark Hardware Jig ...................................
$69.99
3326
12 disc DVD Set....................................................
$59.99
The Easy Bore is a strong, versatile unit! Our hand-
clamped boring jig drills a 35mm hole and two align-
ing 8mm holes at the same setting, which allows you
to accurately install your hinges with ease and speed.
No screwdriver is needed to install, just a hammer to
lightly tap the hinges in place. The hinges have special
plastic inserts around screws which stay embedded in
wood; hinge can then be unscrewed if needed while
finishing etc. The jig has adjustable stops which allow
for different overlays. We use setting number 2 for
1/2”overlay, number 3 for 3/8”overlay. The cast alumi-
num alloy frame also incorporates a depth-adjustable
carbide-tipped 35mm bit with spurs for clean holes in
solid wood, veneers or melamine.
Drilling for Blum
European style
hinges just got a
whole lot easier!
Why not learn
from one of
the best!
