Tables Saw Accessories

6" Pro Dado Set

To create clean edges, square shoulders, make flat bottom grooves and virtually splinter-free cuts

• Negative hook angles
• Features Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance
• Silver I.C.E. Coating prevents build up on the blade surface and keeps the blade running cooler and cleaner
• All blades and chippers come with Freud’s anti-kickback design

Ideal For: Ideal for underpowered saws

Machine Use: Table Saw, Portable Table Saw, Radial Arm Saw

Materials: Veneered plywoods and laminates to solid wood

Set Includes:

• 2 ea. outside blades
• 3 ea. chippers
• Spacers
• Shim Set
• 1 ea. carrying case.

8" Pro Dado Set

To create clean edges, square shoulders, make flat bottom grooves and virtually splinter-free cuts

• Negative hook angles
• Features Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance
• Silver I.C.E. Coating prevents build up on the blade surface and keeps the blade running cooler and cleaner
• All blades and chippers come with Freud’s anti-kickback design

Ideal For: Ideal for underpowered saws

Machine Use: Table Saw, Portable Table Saw, Radial Arm Saw

Materials: Veneered plywoods and laminates to solid wood

Set Includes:

• 2 ea. outside blades
• 3 ea. chippers
• Spacers
• Shim Set
• 1 ea. carrying case.

6" Super Dado Sets

To create clean edges, square shoulders, make flat bottom grooves and virtually splinter-free cuts

• Adjusts in 1/32" increments
• Features Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance
• Silver I.C.E. Coating prevents build up on the blade surface and keeps the blade running cooler and cleaner
• All blades and chippers come with Freud’s anti-kickback design

Ideal For: For cutting slots, grooves, dadoes, and rabbets in softwood or hardwood

Machine Use: Table Saw, Portable Table Saw, Radial Arm Saw

Materials: Veneered plywoods and laminates to solid wood

Set Includes:

• 2 ea. outside blades
• 6 ea. chippers
• Shim Set
• Carrying case.

8" Super Dado Sets

To create clean edges, square shoulders, make flat bottom grooves and virtually splinter-free cuts

• Adjusts in 1/32" increments
• Features Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance
• Silver I.C.E. Coating prevents build up on the blade surface and keeps the blade running cooler and cleaner
• All blades and chippers come with Freud’s anti-kickback design

Ideal For: For cutting slots, grooves, dadoes, and rabbets in softwood or hardwood

Machine Use: Table Saw, Portable Table Saw, Radial Arm Saw

Materials: Veneered plywoods and laminates to solid wood

Set Includes:

• 2 ea. outside blades
• 6 ea. chippers
• Shim Set
• Carrying case.

Dial-A-Width Stacked Dado Sets

To create clean edges, square shoulders, make flat bottom grooves and virtually splinter-free cuts

• Adjusts in .004" increments
• Features Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance
• Silver I.C.E. Coating prevents build up on the blade surface and keeps the blade running cooler and cleaner
• All blades and chippers come with Freud’s anti-kickback design.

Ideal For: Cuts clean flat bottom grooves in materials such as veneered plywoods and laminates to solid wood.

Machine Use: Table Saw,Portable Table Saw,Radial Arm Saw

Materials: Veneered plywoods and laminates to solid wood

Both Sets Includes:

• 2 ea. outside blades
• 5 ea. chippers
• 1 ea. wrench
• 1 ea. carrying case.

Dado Shim Set

These shims allow you to adjust your kerf width by as little as .004" increments. These shim sets are included with all Freud Super Dadoes SD500 series and SD 200 series dadoes. Works with other brand 5/8" arbor hole dadoes as well.

Includes:

• 4 each .004" x 3 1/8" dia. shims
• 2 each .008" x 3 1/8" dia. shims
• 2 each .012" x 3 1/8" dia. shims
• 2 each .020" x 3 1/8" dia. shims

MATCHFIT Setup Gauge

The MATCHFIT Setup Gauge is used for setting up Microjigs® MATCHFIT Dado Stop. The Setup Gauge will allow you to setup for both the left and right side of your table saw blade kerf without having to set up the Matchfit Dado every single time. By Cutting the blade kerf into the gauge it eliminates the steps of having to set the kerfs thickness on the dado stop.

The MATCHFIT Setup Gauge makes setting up the MATCHFIT Dado Stop:

• FAST
• PRECISE
• CONSISTENT

Note: The Setup gauge is not required to use the MatchFit Dado Stop

MATCHFIT Dovetail Router Bit (14-Degree by 1/2")

MICROJIG's exclusive MATCHFIT Dovetail Router Bit makes the MATCHFIT system faster and easier to use than ever before.

The MATCHFIT Dovetail Router Bit is designed especially for the MATCHFIT Dovetail Clamps and dovetail hardware. Although it mills the same 14 degree, 1/2" profile as a standard dovetail bit, its unique design automatically rounds over the sharp top shoulders creating incredibly clean dovetail grooves and virtually eliminating the need for sanding. Experience the difference supreme engineering and attention to detail make.

• Rout incredibly clean dovetail grooves and requires less sanding
• Perfect fit for the MATCHFIT Dovetail Clamp system
• Evacuate chips and dust, reducing friction, and heat, resulting in cleaner cuts.
• 14°, 1/2" profile with unique rounded corners for smoother grooves
• Router collet safety line shows how deep into the collet the bit should be

Note: Gripper Not included

MATCHFIT 1/4" Relief Router Bit

Perfect with the Dovetail Router Bit.

Specially designed to route 1/4" relief grooves in material prior to the MATCHFIT Dovetail Router Bit. The relief bit removes 55% of waste material, which reduces stress on your Dovetail Router Bit. This improves the quality of dovetail grooves and increases the overall lifespan of your MATCHFIT Dovetail Router Bit. Available in 1/2" and 1/4" shank sizes.

How it works.
Make your tracks silky smooth.

• Removes 55% of waste material prior to routing dovetail grooves.
• Laser etched depth guide alls you to dial in cutting depth in a snap.
• The built-in roundover smooths out the top shoulders of the groove to prevent tearout.
• Relieves stress on router and improves lifespan of Dovetail Router Bit.

Specifications:

• 1/4" diameter, 3-degree upshear carbide.
• 11/32” Laser etched depth guide to quickly set cutting depth.
• Built in roundovers for smoother cuts and less sanding.
• Extra wide shoulder reduces vibration and noise.
