Layout & Measuring

6" Digital 3-in-1 Marking / Mortising Gauge

Layout mortises, mark shoulders, scribe circles, the Digital 3-in-1 Marking and Mortising Gauge does everything a traditional gauge does and more. But that's not all. As a digital gauge, it does it all with an accuracy of 1/1000th of an inch. Versatile 3-pin design allows you to set up the gauge in several different configurations, depending on the operation. Solid stainless steel construction.

Features:

• Precision Digital Marking, Mortise, Divider Or Marking, Depth, Height gauges 3-in-1
• Large LCD, 3 Digital reading: inch, metric, inch fractional
• Hardened Alloy Pin
• Precise Marking on Steel & Wood Surfaces
• IP54 Humidity & Dust Resistance
• Precision Drawing & Marking Instrument

Professional Marking Gauge

This marking gauge features a hardened steel cutting wheel, which slices a line and resists following the grain, which is common with pin marking gauges. Constructed of a 8" steel shaft. Slide the gauge in place then tighten the knurled brass knob to secure it.

Features:

• Hardened steel cutting wheel
• Constructed of a 8" steel shaft

Includes:

• 1 ea. Professional Marking Gauge

Wheel Marking Gauge

This tool allows you to make perfect hairline layout marks both with and across wood grain. The single bevel edge wheel scribes a fine line without tearing the wood fibers and does not wander with the wood's grain. Balanced feel.

Features:

• Precision machined solid-brass body and knurled lock nut.
• Brass head with 8" steel rod
• Shaft is graduated 1 mm / 1/32 inch increments
• Can be used as a depth gauge
• Great for quick measurement transfers
• Wheel retracts into face of the gauge for storage
• Free-spinning wheel cuts wood fibers; not tearing
• Designed for comfortable one-handed operation

Ruler Marking Gauge

Note: Ruler Not Included

Made from aluminum, this handy device allows you to convert most shop rulers into a convenient marking gauge. The single adjustment knob allows you to make quick adjustments for depth, parallelism and squareness. The smooth fence like face runs across the edge of your piece you are marking for accurate markings every time. Simply place your ruler in between the two guide sides and secure with the locking knob and your ready to go. The ruler marking guide can be used on rulers from 7/8" wide to 1-1/8" wide.

Features:

• Made of aluminum - converts most shop rulers into a convenient marking gauge
• Single adjustment knob
• Ruler marking guide can be used on rulers from 7/8" wide to 1 1/8" wide
• Make adjustments for depth, parallelism and square ness
• Smooth face runs across the edge of your piece for accurate markings

Multi-Mark
Multi-Purpose Marking and Measuring Tool

The Kreg Multi-Mark (model KMA2900) is an incredibly handy multi-purpose marking and measuring tool, perfect for a wide variety of household and jobsite applications.
›See more product details

×

Multi-Mark Multi-Purpose Marking and Measuring Tool

The Kreg Multi-Mark (model KMA2900) is an incredibly handy multi-purpose marking and measuring tool, perfect for a wide variety of household and jobsite applications. The Multi-Mark features three different scale configurations, a built-in level, a handy 3/16-inch reveal gauge, and much more. Whether you need to transfer a measurement for that last ceramic tile, layout some mitered corners, or just straighten a few simple picture frames, the Multi-Mark is the only tool you'll need to get the job done.

One Tool Does it all

• Layout Mitered Corners
• Set 3/16" Reveals
• Transfer Measurements
• Align / Square Your Projects
• Set Bit / Blade Heights
• Layout Wall Studs
• Use as a Basic Rule
• Marking for Layout
• Use as a Simple Level
• 3-Way Adjustable Rule
• Imperial and Metric Scale
• Compact Design
• Layout Tool
• Trimming Tool
• T-Square
• Depth Gauge
• Torpedo Level
• Story Stick

Close

One Tool Does it all

• Layout Mitered Corners
• Set 3/16" Reveals
• Transfer Measurements
• Align / Square Your Projects
• Set Bit / Blade Heights
• Layout Wall Studs
• Use as a Basic Rule
• Marking for Layout
• Use as a Simple Level
• 3-Way Adjustable Rule
• Imperial and Metric Scale
• Compact Design
• Layout Tool
• Trimming Tool
• T-Square
• Depth Gauge
• Torpedo Level
• Story Stick

ScribeTec™

The ScribeTec™ from Milescraft® is a flexible marking tool with multiple uses around the shop. The articulated arms allow you to adjust to any surface or contour. The tool easily maintains a consistent scribe offset that stays parallel to the work surface every time. The ScribeTec is ideal for scribing molding, cabinet trim, flooring, and a variety of other projects.

Features:

• Easily maintain consistent scribe offset, keeping parallel to surface every time
• Articulating pencil head, for complex angles
• Adjustable writing instrument grip can hold No. 2 pencils, carpenter pencils, and Sharpie® (or similar) markers
• Built-in pencil sharpener for keeping your pencil sharp and your line crisp
• Retractable, spring-loaded, locking precision point for a precise radius

Ideal For Scribing:

Accuscribe PRO

Articulating pencil head increases flexibility and versatility of materials and objects that can be scribed. Allows you to adjust the AccuScribe PRO to accommodate difficult and awkward applications such as scribing around windows and doors. Ideal for transferring lines (for siding around windows), flooring, marking gauge applications, and scribing circles and radii.

Features:

• Flat bottom for precise marking
• Retractable compass point
• Built-in pencil sharpener
• Articulating pencil head
• Increases flexibility and versatility of materials and objects that can be scribed

Great For:

• Making radius
• Marking gauge
• Scribing
• Everyday compass

Point2Point MK2

Equisdistant Measuring, Mark equally spaced Multiple points, for drilling, doweling, jointery pinning, and flat doweling. Simply expand the Ponit to Point meachanisim, find the ideal spacing and lock the 7-point positions, then transfer to component.

Features:

• Center Point Finder
• Increased Accuracy
• 710mm (28") Maximum Extension
• Minimum width 85mm
• 2-point locking mechanism with 7 equidistant marking positions.
• For left or right hand use.
• Ideal for woodworking, arts & crafts, Sewing etc.

Great For:

• Making radius
• Marking gauge
• Scribing
• Everyday compass

MS/PRO 15-Function Multiscribe Profile Matching Tool

The Trend Multiscribe is a multi-function profile matching tool that is used to transfer contours from one shape to another and mark on various materials. For use by all trades, carpenters, joiners and builders, the Multiscribe may be used as a compass, plumb bob, vertical or horizontal level. Steel blade is graduated with 1/4" and 5mm for profiling and features a built-in spirit level and pencil sharpener.

Features:

• 15 Functions
• Parallel, convex, concave and contour scribe
• For all trades
• Built in level vile and pencil sharpener
• Steel blade with 3/16-Inch and 1/4-Inch graduations

Perfect Butt

Trend's 'Perfect Butt' is a simple yet ingeniously elegant solution to an awkward problem faced by many woodworkers, tradesmen's & enthusiasts - scribing in work surfaces, floor & shelving etc. into awkward or oddly shaped areas. It quickly and accurately scribes profiles to ensure a perfect join between two uneven work pieces, every time.

Features:

• Quick & easy to use
• Sprung loaded pencil for consistent scribe contact
• Remains stable whilst scribing
• Profiles single surfaces & complete areas
• Minimize material wastage & costs

Includes:

• 1 ea. Trend Perfect Butt

Square N Tape™

No need to use a builder's square or chalk box; using the peel and stick backing, simply attach SquareNTape™ to any standard tape measure (sold separately) then slide and mark your board with the 8-in-1 SquareNTape™ from FastCap®! SquareNTape™ features include a 90° squared edge that lets you lay it across a board for 90° squaring capabilities. Notches at 1-1/2" and 3-1/2" make it easy to mark 2" x 2" and 2" x 4"s out of wide construction boards. Made in USA.
›See more product details

×

Square N Tape™

No need to use a builder's square or chalk box; using the peel and stick backing, simply attach SquareNTape™ to any standard tape measure (sold separately) then slide and mark your board with the 8-in-1 SquareNTape™ from FastCap®! SquareNTape™ features include a 90° squared edge that lets you lay it across a board for 90° squaring capabilities. Notches at 1-1/2" and 3-1/2" make it easy to mark 2" x 2" and 2" x 4"s out of wide construction boards. SquareNTape™ also has marks at 1-1/2" and 3" for laying out plates for single and double stud layouts; perfect for window and door construction. Marks at 45° and 22-1/2° make it easier to mark angled lines, plus, it has a handy erasable notepad for writing down measurements. Made in USA.

Technical Details:

• Eliminates the need for a builder's square or chalk box
• 90° squared edge lets you lay SquareNTape™ across a board for 90° squaring capabilities
• Squared edge also lets you mark and slide using notches at 1-1/2" and 3-1/2" - ideal for marking door and window plates for single and double stud layouts
• Marks at 45° and 22-1/2° for marking angles
• Handy erasable notepad eliminates the chance you'll forget important measurements
• Made in USA

Close

Technical Details:

• 90° squared edge
• Squared edge also lets you mark and slide using notches at 1-1/2" and 3-1/2"
• Marks at 45° and 22-1/2° for marking angles
• Handy erasable notepad
• Made in USA
