Layout & Measuring

6" Digital 3-in-1 Marking / Mortising Gauge

Layout mortises, mark shoulders, scribe circles, the Digital 3-in-1 Marking and Mortising Gauge does everything a traditional gauge does and more. But that's not all. As a digital gauge, it does it all with an accuracy of 1/1000th of an inch. Versatile 3-pin design allows you to set up the gauge in several different configurations, depending on the operation. Solid stainless steel construction.

Features:

• Precision Digital Marking, Mortise, Divider Or Marking, Depth, Height gauges 3-in-1
• Large LCD, 3 Digital reading: inch, metric, inch fractional
• Hardened Alloy Pin
• Precise Marking on Steel & Wood Surfaces
• IP54 Humidity & Dust Resistance
• Precision Drawing & Marking Instrument

Digital Compass & Divider

There's no guesswork with the Digi Compass + Divider precision drawing and marking instrument.This one-of-a-kind compass features a large LCD display that shows digital readings in inches, fractions, and metric. Use it as a digital compass to scribe perfect circles or arcs, or for stepping out equal distances in odd or even measurements.
›See more product details

×

Digital Compass & Divider

There's no guesswork with the Digi Compass + Divider precision drawing and marking instrument.This one-of-a-kind compass features a large LCD display that shows digital readings in inches, fractions, and metric. Use it as a digital compass to scribe perfect circles or arcs, or for stepping out equal distances in odd or even measurements.

Features:

• Range 0-8" Radius
• Accuracy: 0.01"/6"
• Inch/Metric/Fraction display reading
• Large LCD display
• Super Strong Poly-Fiber Jaws
• Smooth metal thread movement
• Can be used with Pencil Leads or 2 Metal Divider Point (All included)

Includes:

• 1 ea. iGaging Digital Compass & Divider

Close

Features:

• Range 0-8" Radius, Accuracy: 0.01"/6"
• Inch/Metric/Fraction display reading
• Large LCD display
• Super Strong Poly-Fiber Jaws, Smooth metal thread movement
• Can be used with Pencil Leads or 2 Metal Divider Point (All included)

3" Digital Protractor

The Wixey Digital Protractors can be used in any plane.

• 0.1 degree resolution, accuracy, and repeatability
• Sets both miter and bevel angles on almost any machine
• Strong magnets on all blade edges for ease of use
• Blades can be tightened for holding measurements
• 2" wide X 7/8" thick X 4" long
• Compact design for tight locations
• Sets miter saw miter and bevel angles
• Great for drill press and band saw tables

8" Digital Protractor

The Wixey Digital Protractors can be used in any plane.

• 0.1 degree resolution, accuracy, and repeatability
• Sets both miter and bevel angles on almost any machine
• Strong magnets on all blade edges for ease of use
• Blades can be tightened for holding measurements
• 2" wide X 7/8" thick X 9" long
• Long legs for added versatility
• Measure work-piece or construction angles
• Use for marking and layout

Digital Angle Protractor with Rule

This digital protractor/rule allows you to precisely set and measure angles in 0.05 degree increments. The stainless steel arms are graduated inch and metric scale for convenient and immediate linear measuring. Features a hold function, ensuring you never lose your reading, and a reverse reading capability for those hard to calculate angles. The protractor measures angles from 0 to a full 360°. Packaged in a protective plastic pouch with an extra battery.

Features:

• precisely set and measure angles in 0.05 degree increments
• The stainless steel arms are graduated inch and metric scale for convenient and immediate linear measuring
• Hold function, ensuring you never lose your reading
• Reverse reading capability for those hard to calculate angles

Digital Angle Rule 200mm

Two x 7 inch (400mm) rule digital angle rule that calculates angles quickly and accurately and is ideal for woodworking, construction and machining.

Features:

• Digital display for angles.
• Stainless steel rule with metric/imperial scale, scale length 200mm and 7 inch.
• Measuring range from 000.0 deg to 360.0 deg, with accuracy of 0.3 deg.
• Rule locking function.
• Easy operation with two press buttons.
• Auto-shut off in 6 minutes.

Digital Angle Rule 500mm

Two x 18-1/2 inch (960mm) rule digital angle rule that calculates angles quickly and accurately and is ideal for woodworking, construction, and machining.

Features:

• Digital display for angles.
• Stainless steel rule with metric/imperial scale, scale length 500mm and 18-1/2 inch.
• Measuring range from 000.0 deg to 360.0 deg, with accuracy of 0.3 deg.
• Rule locking function.
• Easy operation with two press buttons.
• Auto-shut off in 6 minutes.

Digital Angle Finder

Digital angle finder 8 inch (200mm) with level vial.

Features:

• Large clear LCD display with digital readout to allow easy reading of angles.
• Calculates angles from 0-220 degrees. Up to 360 degrees when locking knob removed. Resolution of 0.05 degree.
• Large aluminum stock for stability and accuracy.
• Robust but lightweight aluminum construction butt.
• Dual metric/imperial scale folding metal blade 50mm wide with locking function.
• Use on internal and external angles to quickly measure an angle saving time and money.
• Use to check saw blade angle to bed.
• Easy operation with three buttons on/off, hold and zero/ABS.
• Readout always reads correctly when used in ABS mode.
• Spirit level vial
• Hold function.
• 90 degree angle check on end of blade.
• Auto-shut off in 5 minutes.

Digital Planer Readout WR510

The Wixey Planer Digital Readout model WR510 has a new angled display for easy viewing as well as "auto shut off." And like the WR500, it fits most portable woodworking planers.

It easily mounts to Dewalt, Delta, Ridgid, Ryobi, Makita, Craftsman and others. It mounts in minutes and is calibrated in seconds.

It displays the thickness of the wood coming out the back of the planer in inches with fractions or millimeters.

Wixey Planer Digital Readout has been redesigned and now has these new features:

• Angled display for easy viewing
• Auto shut off
• Improved hardware and instructions

Remote Readout WR525

Ideal for router lifts - The Wixey Remote Digital Readout is a kit that can be adapted to a number of woodworking machines. Including router lifts, router tables, and shapers. It is a remote display connected with 3 ft. cord that can be disconnected for easy installation and access. The easy to install kit requires drilling 2 small holes in your machine using the drill bit supplied. Mounting hardware is included. Fits router lifts made by Woodpeckers, Jessem, Jointech, and others.

Digital Readout for Router

Keep close tabs on the position of your router lift with this clever remote gauge.Accommodates vertical or horizontal setup. Positional measurements from 0 to 6" read out on a large LCD display in standard, metric and fractional inch modes. Display is connected to the gauge by a 4' wire and features a platform and two rare earthmagnets for mounting on your table surface. Includes vertical, horizontal and slidermounting hardware.

Features:

• Two rare earthmagnets for mounting on your table surface
• Large LCD display
• Standard, metric and fractional inch modes
• Includes vertical, horizontal and slidermounting hardware

6" Digital Inside Caliper

Use this digital inside caliper for fast easy measurement of hole diameters and inside measurements. This is a must have layout tool for all wood turners. Now you can make a lid fit the first time.

The DigCal 1/2"-6" inside Caliper has:

• spring-loaded arm travel
• chrome finished alloy jaws
• Reads in: inch, metric and fractions
• measuring range 1/2" -6"
• accuracy 0.01"
• comes with 1 extra 3V CR2030 Battery
• 1 year battery life (approx.)

6" Digital Outside Caliper

Use this digital outside caliper for fast easy measurement of board thickness and cylinder diameters.

This is a must have layout tool for all wood turners.

The DigCal 0-6" Outside Caliper has:

• spring-loaded arm travel
• chrome finished alloy jaws
• Reads in: inch, metric and fractions
• measuring range 0-6"
• accuracy 0.01"
• comes with 1 extra 3V CR2030 Battery
• 1 year battery life (approx.)

6" ID Digital Caliper with Handle

A must have for any woodworking shop. Now you can easily and accurately measure parts and pieces, measure wood thickness or accurately duplicate projects on your lathe. These digital calipers feature chrome finished alloy jaws with a large LCD display that reads in inch, metric, and fractional (1/64") increments with a measuring range from 0-8" that is accurate to within 0.01". 3V battery and plastic storage case included.

Features:

• Chrome finished alloy jaws
• Large LCD display reads in inch, metric, and fractional (1/64") increments
• Measuring range from 0-8" that is accurate to within 0.01"
• 3V battery and plastic storage case included

8" Digital OD Caliper & Thickness Gauge

Make quick, accurate inside measurements with these new, high quality, digital calipers. The large LCD display makes reading a breeze, and the readings can be set for inch, metric or fractional measurements. Important and convenient Hold function. Perfect for woodworking, woodturning, carpentry, metal fabrication, etc. Supplied with battery.

Features:

• Inch, Metric and Fractional Readings, Hold Function
• Large LCD Display
• Spring-Loaded travel
• Convenient Handle for easier measuring
• Easy Move/Lock System

6" Digital Multi Gauge

Set the heights of router bits and saw blades with greater accuracy! This 3-in-1 digital router combines the functions of three tools: a depth gauge, height gauge and thickness gauge. It is a metal rule with a Super Large LCD display, housed in a heavy-duty polycarbonate frame which allows it to stand freely. The measuring range is 0-6", with a router depth of 0-3.10" and a slot depth of 2.90". It features buttons for on/off as well as zero set functions, and it easily switches readings from inches to metric to fractions at a touch. Two hardened steel measuring anvils (flat and point) are included.

Features:

• 0-6" full range digital gauge: height, depth and welding thickness
• 3-way measuring: horizontal, vertical, 90° angle
• 3-way reading: inch, inch fractional, metric
• Accurate to within 0.001" per 1"
• EZ view with super large LCD display
• 3 angles on gauge body: 70°, 80°, 90°
• Heavy-duty polycarbonate frame for free-standing measuring
• Hardened steel measuring anvils: flat and one with a point
• Locks for accuracy
• Operates on one 3V CR2032 battery (included)

Digital Depth Gauge

Digital depth gauge for router tables and saw benches. Horizontal and vertical measuring.

Features:

• For hand routers, router tables and saw benches.
• LCD readout for mm, imperial and fractions with auto shut off 5 min's.
• Removable pin to allow hole depths to be measured.
• Pin can be parked on arm. Hole depth 2 inch.
• Self standing with magnetic feet and flat back.
• Injection plastic molding with plastic rule.
• Read-out has relative co-ordinate and absolute function.
• 2-3/8 inch wide aperture.

• Digital Depth Gauge
• 1 x 3V CR2032 lithium battery

Snap Depth Gauge

Measure depths from 0 to 4" with inch, metric or fraction readout modes! Spring loaded travel provides accuracy to 0.001". Check the depth of slots, dovetails, mortises,dadoes and more. Quickly quantify table saw runout and measure the flatness of yourblade. Interchangeable 1" and 2" measuring bars included.

Features:

• Measure depths from 0 to 4"
• Inch, metric or fraction readout modes
• Spring loaded travel provides accuracy to 0.001"
• Interchangeable 1" and 2" measuring bars included

Digital Bevel Box

Take the guesswork out of setting up those critical bevel cuts on your table saw, jointer, bandsaw or drill press table. Just set the unit on a flat reference surface, press the ZERO button to calibrate the display then attach it to the saw blade, fence, etc. and precisely adjust to the desired angle. The Angle Cube offering 0.2° accuracy with a resolution of 0.05° at a range of 90°. The large LCD screen makes it easy to read while strong magnets hold the unit to any steel or cast iron surface. Spare battery included, measures 2 3/8" x 2 3/8" x 1 3/8".

Specifications:

• Reading: 0.005°
• Range: 4 x 90°
• Accuracy: +/- 0.2°
• Measures: 2-3/8" x 2-3/8" x 1-3/8"
