Freud Beading Router Bit




These Freud Beading Bits create an attractive bead profile for furniture and millwork. Cut a quarter-round shape bounded by fillets, known as a bead, is produced in one pass by this bit. The width of one fillet is set by the pilot bearing size, while the other is controlled by the depth of cut. A beading bit can be transformed into a corner rounding bit by changing the bearing (and vice versa). Cuts all composition materials, plywoods, hardwoods, and softwoods. Use on CNC and other automatic routers as well as hand-held and table mounted portable routers.

Cat #
Freud #
D
B
h
R
A
H
Price

2563 36-104 3/4" 3/8" 1/2" 1/16" 1/4" 2-3/16" $30.99

2564 36-106 13/64" 3/8" 1/2" 5/32" 1/4" 2-3/16" $30.99

2565 36-108 7/8" 3/8" 1/2" 5/32" 1/4" 2-3/16" $32.99

2571 36-118 3/4" 3/8" 1/2" 3/16" 1/2" 2-1/2" $32.99

2572 36-119 7/8" 3/8" 1/2" 3/16" 1/2" 2-1/2" $33.99

2573 36-120 1" 3/8" 1/4" 1/4" 1/2" 2-1/2" $33.99

2574* 36-122 1-1/8" 3/8" 1/2" 5/16" 1/2" 2-1/2" $35.99

2575* 36-124 1-1/4" 3/8" 5/8" 3/8" 1/2" 2-5/8" $36.99

*Quadra Cut



Product Divider Image

Freud Quadra-Cut Beading Router Bit

Freud Quadra-Cut Router Bit

Freud Qudra-Cut Beading Router Bit





These Quadra-Cut™ beading bits create an attractive bead profile for furniture and mill work. Bearing rides smoothly along the edge of stock. Cuts all composition materials, plywoods, hardwoods, and softwoods. Use on CNC and other automatic routers as well as hand-held and table-mounted routers.

Cat #
Freud #
D
B
h
R
A
H
Price

2574
36-122
1-1/8"
3/8"
1/2"
5/16"
1/2"
2-1/2"
$32.99

2575
36-124
1-1/4"
3/8"
5/8"
3/8"
1/2"
2-5/8"
$33.99

2576
36-126
1-1/2"
3/8"
3/4"
1/2"
1/2"
2-3/4"
$48.99

2580
36-132
2-1/2"
3/8"
1-1/4"
1"
1/2"
3-1/8"
$110.99

2581
36-134
2-3/4"
3/8"
1-3/8"
1-1/8"
1/2"
3-1/4"
$132.99
