Drilling / Boring

Concealed Hinge Jig

The Concealed Hinge Jig takes the guesswork out of installing cabinet doors using concealed hinges. This economical, easy-to-use jig ensures accurate hinge alignment, so you can install doors that fit great and work well. Plus, the Concealed Hinge Jig works with an ordinary drill and the included carbide tipped bit.

Make cabinet door installation easy! Get drill press accuracy with any hand drill.

• Accurate hinge positioning with built-in indexing tabs
• Repeatable results with built-in measuring scales
• Reliable drilling with bit guide and stop collar
• Simple to use with any drill—no special tools needed
• Adjustable cams ensure proper hinge offset
• Durable carbide-tipped drill bit included
• Strong, lightweight materials for easy handling

Intuitive for beginners to use, but robust enough for professionals

The Concealed Hinge Jig is designed to be intuitive for beginners to use, but robust enough for professionals. Just pick out your hinges, look up a few basic mounting instructions that come with them, and then set up the Concealed Hinge Jig by adjusting a pair of built-in cams. After that, you’re set to drill hinge cup holes using any ordinary drill. Whether you’re installing one cabinet door or making doors for an entire kitchen, the Concealed Hinge Jig provides reliable, consistent results.

Drill cup holes for concealed cabinet door hinges

The Concealed Hinge Jig allows you to drill cup holes for concealed cabinet door hinges (sometimes called “Euro hinges”) using just a drill. The jig positions an included carbide-tipped bit exactly at the proper position and offset, and drills to the perfect depth every time thanks to depth stop collar. The jig is simple to use, and it ensures that you can mount cabinet doors that fit great and work properly.

Great for mounting cabinet doors

Concealed hinges are great for mounting cabinet doors because they stay out of sight, they’re adjustable, and they work very well. Mounting them, though, requires drilling a large hole at a very specific position and depth. The Kreg Concealed Hinge Jig takes the guesswork out of drilling those holes, and allows you to do it with nothing more than a drill and the carbide-tipped bit that comes with the jig.

High-quality, carbide tipped bit

The Concealed Hinge Jig consists of a glass-filled nylon base with a hole that receives a drill guide. Indexing cams ensure that the jig positions the bit to drill a hole at the required offset—which is dictated by each hinge—and a built-in stop collar ensures that the cup depth is correct every time. There are even holes that you can use to guide a bit for hinge screw holes. The Concealed Hinge Jig comes with a high-quality, carbide tipped bit to ensure great results.

Cabinet Hardware Kit

The Cabinet Hardware Jig takes the guesswork out of installing cabinet knobs and pulls. The movable edge guide and measuring scales make it easy to position knobs precisely, while adjustable drill guides ensure straight holes for perfect knob and pull positioning every time. Perfect for new construction and for refreshing entire rooms.

Install Knobs and Pulls the Worry-Free Way – with Easy, Repeatable Accuracy

• Adjustable guides for accurate hole placement
• Built-in measuring scales for repeatable results
• Versatile for mounting single and multi-hole knobs
• Adjustable edge guide for easy positioning
• Strong, lightweight materials for easy handling
• Durable hardened-steel drill guides

NOTE: 3/16" (5mm) drill bit required - does not come included.

Intuitive for beginners to use, but robust enough for professionals

The Cabinet Hardware Jig is designed to be intuitive for beginners to use, but robust enough for professionals. All you need is a drill and a 3/16", bit, and the ability to set the jig to match your hardware and the position where you want it to go. Durable polymer construction makes the jig tough but light, and hardened-steel drill guides ensure that you’ll get straight, accurate holes— whether you’re drilling one, a few, or hundreds.

A simple solution

The Cabinet Hardware Jig provides a simple solution for the intimidating task of drilling mounting holes for cabinet knobs and pulls. Whether you’re installing one new knob or dozens of drawer pulls, the Jig ensures that you’ll drill accurately and consistently every time, so you get results that exceed your expectations.

Moveable edge guide and built-in measuring scales

The Cabinet Hardware Jig features moveable, hardened-steel drill guides that lock in place to align with common hole-spacing measurements for cabinet knobs and pulls. This allows you to confidently drill straight, accurately positioned holes. A moveable edge guide and built-in measuring scales (in imperial and metric) ensure that those holes will be positioned where you want it every time, which means you can drill as many holes as you need without the uncertainty and potential mistakes that can come with measuring and marking every one.

Drill straight, accurately positioned holes every time

Whether you’re updating your cabinets or you’re building a project from scratch, adding hardware like knobs and pulls is often one of the final steps—and one of the most intimidating. Drill the holes incorrectly, and it can be very difficult to correct the mistake. The Cabinet Hardware Jig takes all the guesswork out of the process by allowing you to drill straight, accurately positioned holes every time, so you’ll know that every piece of hardware is positioned correctly and consistently.

Drawer Slide Jig

The Drawer Slide Jig takes the guesswork out of installing drawer slides. This easy-to use jig holds slides in position as you drill mounting holes in the cabinet, and it supports drawer boxes while mounting slides to the drawer. Plus, the Jig works with ball-bearing, epoxy-coated, and undermount slides for perfect positioning every time.

Install Drawer Slides the Fast, Easy Way for Drawers That Fit Perfectly Every Time and Slide Smoothly

• Accurate slide positioning with built-in indexing tabs
• Repeatable results without measuring and marking
• Versatile for use in cabinets, cases, and more
• Reversible to mount slides to cabinet and drawer box
• Secure for holding slides in place as you work
• Strong, lightweight materials for easy handling

A Simple Solution

The Drawer Slide Jig simplifies drawer installation by aligning slides in the cabinet and on the drawer. Built-in tabs make the jig easy to align to support the slide inside the cabinet, and to support the drawers as you attach the slides to them. The jig is simple to use, and it ensures that every drawer fits right and operates smoothly.

Take the Guesswork Out of the Process

Whether you’re updating cabinets or you’re building a project from scratch, mounting drawers is always a challenge. The slides have to be level, straight, and positioned properly, or the drawers won’t operate well. The Drawer Slide Jig takes the guesswork out of the process by indexing with the cabinet frame (or side on frameless cabinets) for perfect alignment.

Know That Your Slides are Positioned Correctly

The jig supports the drawer slide level and straight while you install it in the cabinet. Then, the jig clamps on so it protrudes from the cabinet to support the drawer while you drive screws into the drawer box. With this jig, you’ll know that your slides are positioned correctly, so your drawers will operate smoothly.

Support the Drawer Slide as You Drill Mounting Holes

The Drawer Slide Jig consists of two brackets that clamp in place inside the cabinet—one on each cabinet side—and align with the cabinet face frame (or with designated marks on frameless cabinets) to support the drawer slide as you drill mounting holes. The brackets are also reversible to protrude from the cabinet, and then clamp in place perfectly aligned to support the drawer as you mount the slides to the drawer box, too.

Works With Almost All Types of Drawer Slides

The Drawer Slide Jig works with almost all types of drawer slides, including ball-bearing, epoxy-coated, and undermount slides. The Drawer Slide Jig is designed to be intuitive for beginners to use, but robust enough for professionals. All you need are the slides you’ll use, a clamp, and the Drawer Slide Jig, and you’re set to install drawer slides just like the pros. Whether you’re installing one drawer or dozens, the Drawer Slide Jig provides fast, consistent results.
